Main Unit - Icom IC-V8000 Service Manual

[LOGIC BOARD]
REF ORDER
NO. NO.
C5 4030007090 S.CERAMIC
C7 4030006860 S.CERAMIC
C8 4030006900 S.CERAMIC
C9 4030006860 S.CERAMIC
C10 4030006860 S.CERAMIC
C11 4030006860 S.CERAMIC
C13 4030006860 S.CERAMIC
C14 4030006860 S.CERAMIC
C15 4030006860 S.CERAMIC
C16 4030006860 S.CERAMIC
C19 4030006900 S.CERAMIC
C20 4030006860 S.CERAMIC
C23 4030006860 S.CERAMIC
C28 4030006860 S.CERAMIC
C30 4030007090 S.CERAMIC
C31 4030007090 S.CERAMIC
C32 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C33 4030011600 S.CERAMIC
C34 4030009880 S.CERAMIC
C35 4030008900 S.CERAMIC
C36 4030011600 S.CERAMIC
C37 4030006900 S.CERAMIC
C38 4030009970 S.CERAMIC
C39 4030006860 S.CERAMIC
C40 4030006860 S.CERAMIC
C41 4030011600 S.CERAMIC
C42 4030008920 S.CERAMIC
C43 4030008920 S.CERAMIC
C44 4030008770 S.CERAMIC
C45 4030006900 S.CERAMIC
C46 4030008880 S.CERAMIC
C47 4030011600 S.CERAMIC
C48 4030006870 S.CERAMIC
C49 4030011600 S.CERAMIC
C50 4030007170 S.CERAMIC
C51 4030008890 S.CERAMIC
C52 4030007090 S.CERAMIC
C53 4030007110 S.CERAMIC
C54 4030006900 S.CERAMIC
C55 4030006950 S.CERAMIC
C56 4030006870 S.CERAMIC
C57 4030008470 S.CERAMIC
C59 4030007030 S.CERAMIC
C62 4030006860 S.CERAMIC
C64 4030006900 S.CERAMIC
C65 4030006900 S.CERAMIC
C66 4030006900 S.CERAMIC
C67 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C68 4030011600 S.CERAMIC
C69 4030011600 S.CERAMIC
C70 4030006900 S.CERAMIC
C71 4030006900 S.CERAMIC
C72 4030008900 S.CERAMIC
C73 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C74 4030008770 S.CERAMIC
C75 4030011280 S.CERAMIC
C76 4030008900 S.CERAMIC
C77 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C78 4030006900 S.CERAMIC
C79 4030007170 S.CERAMIC
J1 6450002210 CONNECTOR
J2 6510020880 CONNECTOR
J3 6510020880 CONNECTOR
J4 6510021970 S.CONNECTOR AXN330C130P
DS1 5040001760 S.LED
DS2 5040001760 S.LED
DS4 5040001760 S.LED
DS5 5040001760 S.LED
DS7 5040001760 S.LED
DS8 5040001760 S.LED
DS10 5040001760 S.LED
DS11 5040001760 S.LED
DS13 5040002420 S.LED
DS14 5040002420 S.LED
DS16 5040002420 S.LED
DS17 5040002420 S.LED
DS18 5040002420 S.LED
DS19 5030002250 LCD
DESCRIPTION
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 682K-T-A
C1608 JB 1H 333K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 103K-T-A
C1608 JB 1H 182K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 473K-T-A
C1608 JB 1H 473K-T-A
C1608 JB 1H 562K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 223K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 222K-T-A
C1608 JB 1E 104K-T-N
C1608 CH 1H 221J-T-A
C1608 JB 1H 273K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 680J-T-A
C1608 JB 1H 103K-T-A
C1608 CH 1H 040C-T-A
C1608 JB 1H 222K-T-A
C1608 JB 1H 272K-T-A
C1608 CH 1H 150J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1E 104K-T-N
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 333K-T-A
C1608 JB 1H 562K-T-A
C1608 CH 1H 271J-T-A
C1608 JB 1H 333K-T-A
C1608 JB 1H 103K-T-A
C1608 CH 1H 221J-T-A
3017-8821 <AI>
53244-1217
53244-1217
SEC 2422C
SEC 2422C
SEC 2422C
SEC 2422C
SEC 2422C
SEC 2422C
SEC 2422C
SEC 2422C
SML-310MT T86
SML-310MT T86
SML-310MT T86
SML-310MT T86
SML-310MT T86
L1-0256TAM
[LOGIC BOARD]
REF ORDER
NO. NO.
S9 2250000370 ENCODER
SP1 2510001150 SPEAKER
WS1 8600036880
EP1 6910012350 S.BEAD
EP2 6910012350 S.BEAD
EP3 6910012350 S.BEAD
EP4 6910012350 S.BEAD
EP5 6910012350 S.BEAD
EP6 6910012350 S.BEAD
EP7 6910012350 S.BEAD
EP8 6910012350 S.BEAD
EP9 8930057360 LCD CONTACT SRCN-2509-SP-N-W
EP10 0910055312 PCB

[MAIN UNIT]

REF ORDER
NO. NO.
IC1 1130008350 S.IC
IC2 1130007700 S.IC
IC4 1110003200 S.IC
IC5 1190000350 S.IC
IC6 1110005330 S.IC
IC7 1180001250 S.IC
IC8 1180000420 S.IC
IC9 1110003090 IC
Q1 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q2 1590001650 S.TRANSISTOR XP4601 (TX)
Q3 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q4 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q5 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q6 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q7 1530002920 S.TRANSISTOR 2SC4226-T1 R25
Q8 1590001040 S.TRANSISTOR DTA113ZU T106
Q9 1530003220 S.TRANSISTOR 2SC4406-4-TL
Q10 1560000810 S.FET
Q11 1530003220 S.TRANSISTOR 2SC4406-4-TL
Q12 1530003220 S.TRANSISTOR 2SC4406-4-TL
Q13 1590000720 S.TRANSISTOR DTA144EUA T106
Q14 1510000690 S.TRANSISTOR 2SA1734 (TE12R)
Q15 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q16 1530003220 S.TRANSISTOR 2SC4406-4-TL
Q17 1530000370 S.TRANSISTOR 2SC3356-T1B
Q18 1560001100 S.FET
Q19 1580000660 S.FET
Q20 1560001060 S.FET
Q21 1590001010 S.TRANSISTOR DTB113ZK T147
Q22 1590000430 S.TRANSISTOR DTC144EUA T106
Q23 1560001190 FET
Q25 1590001010 S.TRANSISTOR DTB113ZK T147
Q26 1590000720 S.TRANSISTOR DTA144EUA T106
Q27 1580000660 S.FET
Q28 1530002970 S.TRANSISTOR 2SC4684 (TE16R)
Q29 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q30 1510000890 S.TRANSISTOR DTA143TU T106
Q31 1590001320 S.TRANSISTOR DTC143ZUA T106
Q32 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q33 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q34 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
D1 1790001250 S.DIODE
D2 1750000720 S.VARICAP
D3 1750000770 S.VARICAP
D4 1750000720 S.VARICAP
D5 1750000720 S.VARICAP
D6 1790000620 S.DIODE
D7 1790000620 S.DIODE
D9 1750000710 S.VARICAP
5 - 2
DESCRIPTION
EVQ-VENF0124B
045P0804 <KS>
FX2509 P01LO
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
B 5801B
DESCRIPTION
LV2105V-TLM
BU4094BCF-T1
TA31136FN (EL)
M62363FP-650C
NJM12904V-TE1
TA7808F (TE16L)
TA78L05F (TE12R)
LA4425A
2SK1069-4-TL
[USA] only
2SK3074 (TE12L)
3SK272-(TX)
2SK3075 (TE12L)
RD70HVF
3SK272-(TX)
MA2S111-(TX)
HVC375BTRF
HVC376BTRF
HVC375BTRF
HVC375BTRF
MA77 (TX)
MA77 (TX)
HVC350BTRF
S.=Surface mount
