Microwave Data Systems iNet 900 Quick Start Manual page 39

MDS 05-2873A01, Rev. A
DRAFT 6—8/29/01
DATA CHARACTERISTICS
PORTS:
Ethernet:
Interface Connectors:
Data Rate:
Serial (2):
Signaling Standard:
Interface Connectors:
Interface:
Data Rate:
Data Latency:
Byte Length:
OPERATING MODES:
PROTOCOLS:
PHYSICAL INTERFACE:
Ethernet:
Serial:
RADIO CHARACTERISTICS
GENERAL:
Frequency Range:
Frequency Hopping Range:
Hop Pattern:
Frequency Stability:
Simplex Operation:
TRANSMITTER:
Power Output
(at antenna connector):
Duty Cycle:
1. Is this spelling correct or should it be Async?
MDS iNet 900 Installation and Operation Guide
RJ-45 Standard
10-BaseT
EIA-232/V.24
DB-9 female
COM1: DCE / COM2: DTE/DCE
1200–115,200 bps
asynchronous
<10 ms typical
10 or 11 bits
• Configurable as Access Point or Station LAN
Adapter
• CSMA/CA Wireless Protocol with Collision Avoid-
ance (802.11)
• IEEE 802.11 CSMA/CD
• IEEE 802.3 (Ethernet)
• IP/Ethernet (ICMP, UDP, TCP, ARP)
• Mobile IP
• Clear-channel mode for serial async multidrop
protocols including: Modbus, DNP.3, ISO Asyn-
Z?
1
ch , Bisync, BASP, Poll Select.
10BaseT, RJ-45
• EIA/RS-232/V.24, DB-9F, DCE
• EIA/RS-232/V.24/DB-9M, DTE/DCE
902–928 MHz ISM Band
Up to 1019 frequencies within
user-configurable 3.2 MHz zones
Based on network name
40 ppm
User selectable
0.1 to 1.0 watt (+20 dBm to +30 dBm) ±1.0 dB,
set by user
Continuous
31
