OnCell 3470A-LTE
Configuring a VPN Tunnel
To configure a VPN tunnel,
click Edit in the IPSec
Settings screen.
The following table provides the field descriptions.
Field
IPSec enable
Connection name
Connection type
Startup mode
Remote VPN gateway
Local network
Local netmask
Local ID
Remote network
Remote netmask
Remote ID
Description
Select Enable to activate the VPN tunnel.
Enter a descriptive name for the VPN tunnel.
Select one of the following connection types:
Site-to-Site – Select this option to create a VPN tunnel for
•
static local and remote subnets.
• Site-to-Site(any) – Select this option to create a VPN
tunnel between a static local subnet and a dynamic remote
subnet.
Select Start in Initial to set the OnCell G3470A-LTE to initiate
a connection with the remote VPN gateway.
Select Wait for Connecting to set the OnCell G3470A-LTE to
wait for a remote VPN gateway to initiate a connection.
Enter the WAN IP address of the remote VPN gateway.
Enter the remote VPN server subnet IP of the local network.
Enter the remote VPN server subnet netmask of the local
network.
Enter an ID (IP/FQDN/User_FQDN) to identify and authenticate
the local VPN gateway.
Enter the remote VPN server subnet IP of the remote network.
Enter the remote VPN server subnet netmask of the remote
network.
Enter an ID (IP/FQDN/User_FQDN) to identify and authenticate
the remote VPN endpoint.
3-21
Web Console Configuration
Factory Default
Disable
Site-to-Site
Start in Initial
