There are two different slider bars in the section 'Steering wheel':
The upper bar 'Wheel angle' can adjust the maximum turning angle of the CSL
Elite Racing Wheel, so the functionality is identical with the option 'SEN' in tun-
ing menu (see chapter 'Tuning Menu' of this manual for more detailed informa-
tion). Please note that in tuning menu the value for 'SEN' must be set to 'OFF/
Aut' to allow the PC* driver to take the control. If in tuning menu 'SEN' is set to
any other value than 'OFF/Aut' the value set in tuning menu is applied and valid
and the PC* driver has no influence.
The lower bar 'Dampering strength' is an additional fine tuning possibility for the
tuning menu option 'DPR' (see chapter 'Tuning Menu' of this manual for more
detailed information).
In section 'Pedals' there is only the one checkbox called 'Combined pedals'. Ac-
tivate this checkbox if the game or software uses only one input (I/O) for brake
and throttle pedal signals (negative signal for brake, positive signal for throttle).
This might solve problems especially with older games.
In section 'Gear shifts' there is only one checkbox called 'Map sequential shift-
er to the shifter paddles'. Usually shifters connected to the SHIFTER2 port
are mapped to different inputs (I/Os) than the shifter paddles at the Fanatec
®
steering wheels. If you want to change the mapping so that the used inputs for
these shifters are identically mapped as for the Fanatec steering wheel shifter
®
paddles activate this checkbox.
If you go to the PC* driver page 'Update' you will see this window:
*PC compatibility not tested nor endorsed by Sony Interactive Entertainment LLC.
