8-Port Fast Ethernet
Desktop Switch
Manual
DN-60012

Introduction

The DN-60012 is a compact Ethernet desktop switch that provides wire-speed, a
Fast Ethernet switching function which allows high-performance, low-cost
connections to 10M/ 100M bps Ethernet network. The Ethernet Switch delivers all
the advantages of a switching hub in a compact desktop size and is ideal for small
office or SOHO network users.
This switch provides 8 auto-sensing 10/100 Mbps Ethernet RJ-45 ports which
automatically detect the speed of the devices that you plug into them. This
switching function allows Full/Half-duplex devices to communicate on the same
network without having to replace any infrastructure. This flexible feature allows
your network a timely, economical migration to DIGITUS network switch.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DN-60012 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Digitus DN-60012

  • Page 1 Manual DN-60012 Introduction The DN-60012 is a compact Ethernet desktop switch that provides wire-speed, a Fast Ethernet switching function which allows high-performance, low-cost connections to 10M/ 100M bps Ethernet network. The Ethernet Switch delivers all the advantages of a switching hub in a compact desktop size and is ideal for small office or SOHO network users.
  • Page 2: Key Features

    Four (4) adhesive-backed rubber feet attached. IMPORTANT: If any piece is missing or damaged, please contact your local dealer or reseller for service. Product Specifications DN-60012 (8-Port 10/100Base-TX Fast Ethernet Switch) Ports: 8-Port 10/100Base-TX MAC Address: 1K Mac address table...
  • Page 3: Hardware Description

    Hardware Description The Front Panel The front panel consists of LED Indications. LED Indicators Per Device: Power Per Port: LINK/ACT (Link/Activity) Power Indicator LINK/ACT Indicators Figure 1. Front panel view Status Color Description Power Green The switch is supplied with suitable power. LINK/ACT The port is not linked successfully with the device.
  • Page 4: Troubleshooting

    RJ-45 Ports (Auto MDI/MDIX) 8 auto-sensing ports of 10Base-T, 100Base-TX connections. [In general, MDI means connecting to another Hub or Switch while MDIX means connecting to a workstation or PC. Therefore, Auto MDI/MDIX means that you can connect to another Switch or workstation without changing pin-to-pin or crossover cabling.] DC Power Connector Plug the female connector into the switch and male connector into a power outlet.
  • Page 5 NOTE: Do not plug a standard telephone cord into an RJ-45 port. This may damage the switch Hereby ASSMANN Electronic GmbH, declares that this device is in compliance with the requirements of Directive 2014/30/EU (EMC), Directive 2014/35/EU (LVD) and the Directive 2011/65/EU for RoHS compliance.
