1.1
SUMMARY
This specification shall define the electrical and mechanical characteristics and requirements for a continuous-
duty, single-phase, solid-state uninterruptible power system (UPS). The UPS shall provide high-quality mains
power for sensitive, electronic equipment loads. The UPS is not designed to support large inductive or half-wave
rectified loads, for example: motors, compressors, vacuum pumps, electric drills, laser printers and hair dryers.
1.2
STANDARDS
The UPS shall be designed in accordance with applicable sections of the current revision of the following
documents. Where a conflict arises between these documents and statements made herein, the statements in this
specification shall govern.
Safety-IEC62040-1:2008 version
Emission (Low limits – Conducted and radiated):
•
IEC/EN/AS 62040-2 2nd Ed (Cat 2 – Table 1)
•
CISPR22 Class A (RFI)
•
IEC/EN/AS61000-3-12 (Harmonics)
Immunity (High commercial and light industry immunity levels for enclosure, power, signal and control
ports):
•
IEC/EN/AS 62040-2 2nd Ed (Cat 2 – Table 6) for IEC/EN/AS:
• 61000-4-2 Electrostatic discharge
• 61000-4-3 Radiated E-RFI fields
• 61000-4-4 Fast E transients
• 61000-4-5 Surges/Lightning
• 61000-4-6 Conducted RFI
Transportation and Shipping- ISTA Procedure 1E Certification
Additional Agency Compliance:
• C-Tick (Liebert in Australia / New Zealand will pursue certification)
• WEEE and RoHS (6 by 6)
The 230 VAC UPS units will be
tick (C√) mark.
SLI-23197_Rev 1
®
Liebert
10000VA RT230 Rack Configuration
GUIDE SPECIFICATIONS
1.0 GENERAL
TUV and GS
listed and will bear the CE compliance mark and Australia C-
™
GXT4
1
Guide Specifications
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Emerson Liebert GXT4-6000RT230
Summary of Contents for Emerson Liebert GXT4-6000RT230
- Page 1 ® ™ Liebert GXT4 10000VA RT230 Rack Configuration GUIDE SPECIFICATIONS 1.0 GENERAL SUMMARY This specification shall define the electrical and mechanical characteristics and requirements for a continuous- duty, single-phase, solid-state uninterruptible power system (UPS). The UPS shall provide high-quality mains power for sensitive, electronic equipment loads.
-
Page 2: System Description
Liebert GXT4-10000RT230 SYSTEM DESCRIPTION 1.3.1 Modes of Operation The UPS shall be designed to operate in the following modes: A. Normal - During normal operation, mains power shall provide energy to the UPS. The filters, the power factor correction circuit and the inverter shall process the mains to provide computer-grade power to connected loads. -
Page 3: Design Requirements
Liebert GXT4-10000RT230 1.3.2 Design Requirements A. Voltage: Nominal mains/output voltage specifications of the UPS at rated load shall be: Mains The UPS shall operate from 230V, 50Hz without the use of selector switches or voltage taps. Mains wiring must be 2-wire (L, N) plus earth ground. Output Output voltage is present at terminals L and N. -
Page 4: Performance Requirements
Liebert GXT4-10000RT230 1.3.3 Performance Requirements 1.3.3.1 Mains to UPS A. Voltage: The point at which the UPS transfers to battery operation shall be dependent on the amount of load that the UPS is supporting. The following range defines where the UPS will transfer to battery and where it returns to operating from mains: Low Line Voltage Range GXT4-... - Page 5 Liebert GXT4-10000RT230 1.3.3.2 Mains Output, UPS Inverters A. Voltage Configuration: 50Hz, single-phase, 2-wire-plus-ground. Default setting 230V. Output L-N voltage shall be selectable via the included UPS configuration program. Optional settings shall be 200/208 /220V or 240V. The UPS shall adjust sine wave amplitude to produce the selected voltage to match the mains.
-
Page 6: Environmental Conditions
Liebert GXT4-10000RT230 ENVIRONMENTAL CONDITIONS A. Ambient Temperature Operating: 0°C to 40°C (32°F to 104°F) Storage: -15°C to +50°C (5°F to 122°F) 20°C (68°F) for optimum battery storage. Battery systems should not be stored for extended periods above 25°C (77°F). B. Relative Humidity Operating: 0 to 95% non-condensing. - Page 7 Liebert GXT4-10000RT230 2.0 PRODUCT FABRICATION All materials and components making up the UPS shall be new, of current manufacture and shall not have been in prior service except as required during factory testing. All relays shall be provided with dust covers. 2.1.1 Wiring Wiring practices, materials and coding shall be in accordance with the requirements the standards listed in Section 1.2 and other applicable codes and standards.
- Page 8 Liebert GXT4-10000RT230 COMPONENTS 2.2.1 Input Converter 2.2.1.1 General Incoming mains power shall be converted to regulated DC power by the input converter for supplying DC power to the inverter. The input converter shall provide input power factor correction (PFC) and input current distortion reduction.
-
Page 9: Display And Controls
Liebert GXT4-10000RT230 2.2.2.5 Output Protection The UPS inverter shall employ electronic current limiting circuitry for protection during Normal mode and battery operation and the UPS shall employ input circuit breaker protection during Bypass mode operation. 2.2.3 Display and Controls 2.2.3.1 General The UPS shall be provided with a microprocessor-based control and a status display section designed for convenient and reliable user operation. -
Page 10: Automatic Transfers
Liebert GXT4-10000RT230 A maintenance bypass circuit shall be provided as an integral part of the UPS. The maintenance bypass shall have a break-before-make transfer, shall have a maximum detect and transfer time of 4-6 milliseconds and shall be a double-pole device. The maintenance bypass shall be configured to wrap around the PFC converter, battery charger, DC-DC converter, inverter and battery. -
Page 11: On-Board Communication
Liebert GXT4-10000RT230 ON-BOARD COMMUNICATION The Liebert GXT4 shall offer multiple communication options such as: ® ® A. USB: All models shall work with the Power Management system in Microsoft Windows 2000, Windows ® ® XP, Windows Vista , Linux and Mac OS X, Window 7, Window 8. -
Page 12: Configuration Program
• Modify the shutdown setting of the Any Mode Shutdown. • Select the number of external battery cabinets connected to the UPS to adjust the remaining run time calculated by Emerson software products (default is zero) ® SLI-23197_Rev 1 Guide Specifications...
