Power Protection for Business-Critical Continuity Liebert GXT-MT 1 - 3 kVA True On Line Double Conversion UPS User Manual... - Page 2 V2.11 Revision date: September 29, 2005 Emerson Network Power provides customers with technical support. Users may contact the nearest Emerson local sales office or service center. While every precaution has been taken to ensure accuracy and completeness in this manual, Emerson Network Power assumes no responsibility and disclaims all liability for damages resulting from use of this information or for any errors or omissions.
-
Page 3: Table Of Contents
Table of Contents Contents Safety Instructions Description of commonly used notations Product Introduction System Description Installation Connection and operation 10-13 Operating modes 14-15 Communication port Software Maintenance 18-19 Troubleshooting Technical data 21-22 Appendix: Back Panel 23-24 Page 2 V2.11 Emerson Network Power... -
Page 4: Safety Instructions
Safety Instructions Safety Instructions As dangerous voltages are present within the UPS, only an Emerson technician or an Emerson-authorized technician is permitted to open it. Failure to observe this could result in electric shock risk and invalidation of any implied warranty Transport •... - Page 5 • Please replace the fuse only by a fuse of the same type and of the same amperage in order to avoid fire hazards. • Do not dismantle the UPS system Page 4 V2.11 Emerson Network Power...
-
Page 6: Description Of Commonly Used Notations
1. Description of commonly used notations Some or all of the following Notations may be used in this manual and may appear in your application process. Therefore, all users should be familiar with them and understand their explanations. Page 5 V2.11 Emerson Network Power... -
Page 7: Product Introduction
Model No. on the rear panel of the UPS. Model Number Runtime GXT1000-MT Standard GXT1000L-MT Long Run GXT2000-MT Standard GXT2000L-MT Long Run GXT3000-MT Standard GXT3000L-MT Long Run Page ６ V2.11 Emerson Network Power... -
Page 8: System Description
CAPACITY LEDs In the battery operation, the LEDs indicate the capacity of the batteries: 2nd LED 0-25 % 3rd LED 26%-50 % 4th LED 51%-75 % 5th LED 76%-95 % 6th LED 96%-100 % Page ７ V2.11 Emerson Network Power... -
Page 9: Installation
Open the terminal block cover located on the rear panel of the UPS; please refer to the appearance diagram. For 1KVA UPS, it is recommended to select the 1.5mm wire. For 2/3KVA, it is recommended to select the 2.5mm wire. Page ８ V2.11 Emerson Network Power... - Page 10 11) If it is necessary to connect the inductance load such as a monitor or a laser printer to the UPS, the start-up power should be used for calculating the capacity of the UPS, as its start-up power consumption is too big when it is started. Page ９ V2.11 Emerson Network Power...
-
Page 11: Connection And Operation
Use one cord for every 5A load. Model No. Output Socket (pcs) Terminal Block GXT1000-MT / GXT1000L-MT 4(CE) GXT2000-MT / GXT2000L-MT 6 / 4(CE) Nil /Available GXT3000-MT / GXT3000L-MT 4(CE) Available Page １０ V2.11 Emerson Network Power... - Page 12 Fully charge the batteries of the UPS system by leaving the UPS system connected to the mains for 8 hours. You may use the UPS system directly without charging it but the stored energy time may be shorter than the nominal value specified. Page １１ V2.11 Emerson Network Power...
- Page 13 • One end of the external battery cord is a plug for connecting the UPS and the other end has 3 (or 2) open wires for connecting the battery pack. Page １２ V2.11 Emerson Network Power...
-
Page 14: Connection And Operation
UPS will start to charge the battery pack. Caution! The output sockets of the UPS system may still be electrically live even if the power supply system has been disconnected or the Bypass switch is on “OFF” position. Page １３ V2.11 Emerson Network Power... -
Page 15: Operating Modes
“ON” button on the front panel is pressed 2) For more than 1 second again, the buzzer will stop beeping (in silence mode). Press the “ON” button once again for more than 1 second to resume the alarm function. Page １４ V2.11 Emerson Network Power... - Page 16 4. Abnormality mode In case the fault LED is turned on when the UPS is in use, it shows that the UPS is operating in abnormal mode. Page １５ V2.11 Emerson Network Power...
-
Page 17: Communication Port
Description Pin # UPS Fail Output Summary Alarm Output Input Remote Shutdown Input Common Input Bypass Output Output Battery Low Figure 16.2: DB-9 Interface of AS400 UPS ON Output communication protocol Line Loss Output Page １６ V2.11 Emerson Network Power... -
Page 18: Software
Connect the software cable Follow the on-screen instructions to install the software. When your computer restarts, the WinPower software will appear as a green plug icon located in the system tray, near the clock. Page １７ V2.11 Emerson Network Power... -
Page 19: Maintenance
Normally, the batteries should be charged and discharged once every 4 to 6 months. Charging should begin after the UPS shuts down automatically in the course of discharging, the standard charging time for the standard UPS should be at least 12 hours. Page １８ V2.11 Emerson Network Power... - Page 20 8) Batteries contain hazardous voltage and current. Battery maintenance such as the battery replacement must be carried out by qualified personnel who are knowledgeable about batteries. No other persons should handle the batteries. Page １９ V2.11 Emerson Network Power...
-
Page 21: Troubleshooting
Please have the following information at hand before calling the After-Sales Service Department: 1. Model number, serial number 2. Date on which the problem occurred 3. Detailed description of the problem Page ２０ V2.11 Emerson Network Power... -
Page 22: Specifications
Class B Radiated Emission Environmental Item Normal range Ambient temperature 0°C~40°C Relative humidity Less than 90% Condensing Lower than 1000m; no derating; Altitude 1000~1500m; 1% derating for every 100m rise Storage temperature -0°C~40°C (excluding battery) Page ２１ V2.11 Emerson Network Power... -
Page 23: Electrical Data
Radiated Emission: EN50091-2 ..............Class B Harmonic Current: EN61000-3-2 Voltage Fluctuations and Flicker: EN61000-3-3 EMS: EN61000-4-2(ESD) ................Level 4 EN61000-4-3(RS) ..................Level 3 EN61000-4-4(EFT) ..................Level 4 EN61000-4-5(lighting surge) ................Level 4 EN61000-2-2 (Immunity to low frequency signals) Page ２２ V2.11 Emerson Network Power... -
Page 24: Appendix: Back Panel
Liebert GXTMT Series Installation and User Manual Appendix: Back Panel 1-3 kVA UPS Appendix－Back Panel Back View of GXT1000-MT and GXT1000L-MT Figure 1: Back View of 1KVA & 1KVAS Back View of GXT2000-MT and GXT2000L-MT Page ２３ V2.11 Emerson Network Power... - Page 25 Liebert GXTMT Series Installation and User Manual 1-3 kVA UPS Appendix: Back Panel Back View of GXT3000-MT and GXT3000L-MT Page ２４ V2.11 Emerson Network Power...
