- Page 1 ® INVER SIO N TABLE Assembly Instructions YEAR...
-
Page 3: Important Safety Instructions
BEFORE YOU BEGIN: Review all steps before beginning assembly and read all precautions before using the inversion table. Carefully adhere to the Assembly Instructions and Owner’s Manual to help ensure safety and product integrity. IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE INVERSION TABLE. WARNING WARNING - To reduce the risk of injury to persons: •... -
Page 4: Items For Assembly
Items for Assembly Items are not shown to scale. If you have any questions on assembly, contact Customer Service at 1-800-847-0143 or visit our website at invertalign.com ITEMS FOR ASSEMBLY ITEM NUMBER ITEMS FOR ASSEMBLY ITEM NUMBER ITEMS FOR ASSEMBLY ITEM NUMBER A-Frame IA-2500... -
Page 5: Before Beginning
Before Beginning Before reading further, study the drawing below to familiarize yourself with the important components of your new InvertAlign® inversion table. Head Pillow Bed Frame Extension Table Bed Traction Support Handles 3-Hole Roller Hinge Height-Selector Locking Pin Spreader Arms Main Shaft Angle Tether Crossbar... - Page 6 Step Figure 1 Lower Bolt (1) Upper Bolts (2) Assemble the Table Bed (IA-1305) and Bed Frame Extension (F1-1380) NOTE: This assembly will be referred to as Table Bed (IA-1305) for the remainder of the Assembly Instructions. • Locate the following items to assemble the Table Bed: Table Bed - Upper Portion (IA-1305A) Table Bed Frame (IA-1305) Bed Frame Extension (F1-1380)
- Page 7 Step 2 Figure 4 Assemble the Stability Feet (IA-1101) to the A-Frame (IA-2500) • Steady both sides of the A-Frame so that the legs will not swing ope and turn the A-Frame so that the base points upward (Figure 4). This will give you downward leverage to properly assemble the Stability Feet. •...
- Page 8 Step 4 Figure 7 Install the Roller Hinges (F5-1064) onto the Table Bed (IA-1305) • For ease-of-assembly, rest the Table Bed against the Crossbar of the A-Frame (Figure 7). • Open the Cam Locks on each side of the Table Bed (Figure 8). •...
- Page 9 Step 5 Figure 11 Attach the Table Bed (F1-1305) to the A-Frame (IA-2500) • Pick up the Table Bed, holding each side near the Roller Hinges, and stand in front of the A-Frame where the Crossbar is located (refer to Figure 6 to determine A-Frame Front). •...
- Page 10 Step 6 Figure 14 Insert the Main Shaft (NX-1640) into the Table Bed • With the Height Adjustment Settings on the Main Shaft facing up, slide the end of the Main Shaft into the Main Shaft Housing (Figure 14) on the Table Bed. •...
- Page 11 Step 7 Figure 16 Install the Foam Rollers (F5-1051) • Push down on the Easy Reach Ratchet to open the Front Ankle Bar for ease of assembly. • Slide the Foam Rollers (F5-1051) over each side of the Front Ankle Bar (Figure 16) Tip: To assist with assembly, repeatedly rotate the Foam Roller while pushing it onto the Front Ankle Bar.
- Page 12 Step 9 Figure 19 Attach the Angle Tether (F5-1007) to Limit the Degree of Rotation • The Angle Tether will come pre-assembled to the A-Frame. • Unfold the adjustable Angle Tether and clip it to the U-Bar on the underside of the Table Bed (Figure 19). Attach the Head Pillow (EP-1105) •...
- Page 13 Adjustments / Maintenance / Storage Figure 22 Adjustments: Changing the Roller Hinge Setting To adjust the Roller Hinge setting, you’ll need to fully remove the Table Bed from the A-Frame. • Remove the Angle Tether from the U-Bar located on the underside of the Table Bed. •...
- Page 15 If you have any problems assembling the equipment, or questions about its use, please contact customer service at: STL International, Inc. Toll Free (Phone) 800-847-0143 (Fax) 800-847-0188 mail@invertalign.com www.invertalign.com MDSS GmbH Any modification to Schiffgraben 41 this device will void 30175 Hannover, Germany the UL Listing.
