Advantech EKI-2712G-4FPI Startup Manual

EKI-2712G-4FPI
Unmanaged Redundant Industrial Switch
Overview
The EKI-2712G-4FPI is a new generation of
unmanaged switches. With 8 RJ-45 and 4 SFP
ports, they provide up to 30 watts per port to fulfill
high power consumption PD (Power Device)
requirements.
Packing List
Before installation, please make sure that you
have received the following:
• 1 x EKI-2712G-4FPI Unmanaged Switch
• 1 x Wall mounting bracket with screws
• 1 x DIN-rail Mounting Bracket and Screws
• 1 x Startup manual
• If anything is missing or damaged, contact your
distributor or sales representative immediately.
User Manual
For more detailed information, please refer to the
full manual which can be found on the Advan-
tech's website.
Notes
For more information on this and other Advantech
products, please visit our websites at:
http://www.advantech.com/products/unmanaged-
industrial-ethernet-switches/sub_1-2mlk0j
For technical support and service:
http://www.advantech.com/support/
This startup manual is for EKI-2712G-4FPI
1st Edition
June 2018
Specifications
General
• Compatibility: IEEE 802.3, 802.3u, 802.3x,
802.3az, 802.3ab
• LAN: 10/100/1000 Base-TX
• SFP: Up to 110 km (depends on SFP)
• Ethernet RJ-45 Distance: Up to 100 m
• Connectors:
8 x 10/100/1000Base-T/TX RJ-45
4 x SFP (mini-GBIC)
• Switch Architecture: Store and Forward
• Power Requirements: 48~55 V
Power Input with reverse polarity protection.
• Power Consumption: 15 Watts Max. @48V
(System)
• Power Budget: 120W
• Dimensions (W x H x D): 74 x 152 x 105 mm
• Enclosure: IP30
• Operating Temperature:
-40 ~ 75°C (-40 ~ 167°F)
• Storage Temperature: -40 ~ 85°C
(-40°F ~ 185°F)
• Operating Humidity: 10 ~ 95%
(non-condens- ing)
• Storage Humidity: 0 ~ 95%(non-condensing)
• Safety: UL61010
• EMC: CE, FCC Class A
• Warranty: 5 years
• Altitude: up to 2000 m
