The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards:
◆ Do NOT use power sources other than those specified.
This installation should be made by a qualified service person and
should conform to all local codes.
1
PIXIM Digital Day/Night Vandal Resistant Dome Camera
Advertisement
Table of Contents
Related Manuals for Genie CCTV PIXIM VRD83SPX
Summary of Contents for Genie CCTV PIXIM VRD83SPX
- Page 1 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
-
Page 2: Table Of Contents
■ Contents How to Use the Camera Features ■ Menu Warnings and Precautions ■ Settings ㆍ PRESETS Components ㆍ EXPOSURE ㆍ WDR Names and Functions of Parts ㆍ WHITE BALANCE ■ LENS ㆍ DAY&NIGHT ■ OSD ㆍ IMAGE ADJ. ■ VBS-EXTRA ㆍ... -
Page 3: Features
■ Features Warning ■ The camera requires periodic inspection. High Resolution Colour for Crisp, Motion Detection Contact an authorised technician to carry out the inspection. Clear Video Since the camera detects motion without any ㆍProgressive image capture additional external sensor, you can monitor ㆍ690TVL Effective activity more efficient. - Page 4 ■ Precautions Do not drop the camera or protect Do not expose the camera to Do not install the camera in Do not install or use the camera in an it from physical shocks. radioactivity. extreme temperature conditions. environment where the humidity is high. Only use the camera under conditions It can cause the image quality to be It can cause malfunctions to occur.
-
Page 5: Components
■ Components Names and Functions of Parts ■ 1. COLOUR DOME CAMERA ① ② 2. SCREWS ③ 3. WRENCH ④ 4. WIRE FOR VBS-EXTRA ⑤ 5. INSTRUCTION GUIDE PIXIM Digital Day/Night Vandal Resistant Dome Camera PIXIM Digital Day/Night Vandal Resistant Dome Camera... -
Page 6: Names And Functions Of Parts
■ Names and Functions of Parts Names and Functions of Parts ■ LENS : Vari-Focal DC Auto Iris Lens ① VBS-EXTRA FOR CONNECTING TO LCD ③ Please use the supplied wire when connecting to an external monitor. VBS-EXTRA SMPS PCB FOR DUAL POWER - IF APPLICABLE ④... -
Page 7: Installation
■ Installation 1. Dome Base Mounting - Open the dome cover by loosening the 3 screws using the special Security Screws wrench provided. with "O" ring - Mount the base of camera to a sturdy surface using the 4 screws (1.5 inch) and the 4 premade holes on the base of the dome. -
Page 8: How To Use The Camera
■ How to Use the Camera ■ Menu ■ Settings Settings can be made using the 5 buttons located in the camera. SETUP menu ㆍNORMAL ㆍINDOOR ㆍOUTDOOR PRESETS ㆍBACKLIGHT ㆍLENS SELECT ㆍBLC ㆍEXPOSURE MODE ㆍAGC EXPOSURE ㆍDNR ㆍHIGHLIGHT ㆍCOLOR ROLL ㆍSENS-UP ㆍMIDDLE ㆍHIGH... -
Page 9: ㆍ Presets ㆍ Exposure ㆍ Wdr
■ How to Use the Camera SETUP EXPOSURE Select the function Change the status PRESETS NORMAL using the UP or using the LEFT or EXPOSURE.. DOWN button. RIGHT button. MIDDLE SETUP WHITE BALANCE PRESETS NORMAL DAY&NIGHT AUTO.. EXPOSURE.. IMAGE ADJ.. SPECIAL.. - Page 10 ■ How to Use the Camera ● BLC : To optimize the scene when there is a strong backlight behind SETUP the object. PRESETS NORMAL - ON / OFF selectable EXPOSURE.. MIDDLE ADVANCED BLC SETUP WHITE BALANCE PERCENTILE DAY&NIGHT AUTO.. IMAGE ADJ..
-
Page 11: ㆍ White Balance ㆍ Day&Night ㆍ Image Adj
■ How to Use the Camera WHITE BALANCE Use the White Balance function to adjust the screen colours. Note 1. Position the cursor to point to WHITE BAL on the SETUP menu screen, select using the Up and Down buttons. •... - Page 12 ■ How to Use the Camera IMAGE DAY&NIGHT SETUP FREEZE NIGHT MODE BW+burst FLIP COLOR SHARPNESS TIME DELAY COLOR GAIN GAMMA PREVIOUS PAGE.. FOCUS.. PREVIOUS PAGE.. ● COLOR : The picture is displayed in colour. ● B/W : The picture is always displayed in black and white. ●...
-
Page 13: Camera Id
■ How to Use the Camera ● FOCUS : To adjust the lens focus. SPECIAL CAMERA ID FOCUS DETECTOR VIDEO OUT.. FOCUS METER DZOOM SET FOCUS REGION.. MOTION PREVIOUS PAGE.. PRIVACY MASK.. SYNC RESET SET FOCUS REGION PREVIOUS PAGE.. ● CAMERA ID : User can enter a unique name for the respective camera. The maximum length of the ID is ten characters. - Page 14 ■ How to Use the Camera ① Select the position where the ID is to be displayed by using the MOTION DETECTION LEFT and RIGHT buttons. ACTIVITY THR. ● VIDEO OUT : Move the cursor to select the video system MESSAGE TIME - VIDEO STANDARD : You can control NTSC / PAL, Video level, SETUP MOTION ZONE..
- Page 15 ■ How to Use the Camera EXIT MENU. ENABLE MASKS (1 to 6) ENABLE MASKS (7 to 12) MASK 1 MASK 7 MASK 2 MASK 8 EXIT MENU MASK 3 MASK 9 VERSION : 7.3.2-7.0.281 MASK 4 MASK 10 MASK 5 MASK 11 SAVE&EXIT MASK 6...
-
Page 16: Troubleshooting
■ Troubleshooting If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an Problem Solution authorised technician. Problem Solution Colour is not correct. • Check the WHITE BAL settings in the SETUP menu. Nothing appears on •... -
Page 17: Specifications
■ Specifications ITEM SPEC. 170mA (AC24V) / 250mA (DC12V) Power Consumption 160mA (DC12V Only) Image Sensor PIXIM 1/3" High Sensitivity Digital Sensor Signal processing 17-bit Digital Signal Processing Transfer Format Progressive with Segmented Frames Sync. System Internal / Line Lock Effective Pixels 758(H) x 540(V) Lens... -
Page 18: Pixim Digital Day/Night Vandal Resistant Dome Camera
VRD83SPX/12 PIXIM Digital Day/Night Vandal Resistant Dome Camera Instruction Guide GENIE CCTV LTD. CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT Tel : +44 (0) 1707 330541 Fax : +44 (0) 1707 330543 www.geniecctv.com Edition. GN-OCTOBER 2011...
