- Page 1 14 M 174 E 14 M 174 E ENGLISH ENGLISH BATTERY OPERATED HYDRAULIC CRIMPING TOOL B54MD-D6 B54MD-D6E OPERATION AND MAINTENANCE MANUAL...
- Page 2 WARNING LABELS Tool Before using the tool, carefully read the instructions in this manual. When operating the tool, keep hands away from the danger zone. See page 8. Battery Never throw batteries into fi re or water. Always recycle the batteries. Do not discard batteries into domestic refuse or waste disposal.
-
Page 3: General Characteristics
BATTERY OPERATED HYDRAULIC CRIMPING TOOL 1. GENERAL CHARACTERISTICS B54MD-D6 B54MD-D6E TOOL TYPE: Application range: suitable for installing electrical compression connectors for conductors up to 150 mm (300 MCM) Crimping force kN (sh ton): 54 (6) Rated operating pressure bar (psi):... -
Page 4: Head Rotation
2. INSTRUCTIONS FOR USE The tool can be held in one hand while positioning the connector with the other. Residual battery capacity level is automatically displayed after every cycle. The part reference includes the following: – Basic tool complete with crimping jaws with thermoplastic protection. –... -
Page 5: Battery Status
2.6) Battery status (Ref. to Fig. 2) The battery is equipped with LED indicators that indicate the remaining battery life at any time by pressing the adjacent button (P). 4 LEDs illuminated: Fully charged 2 LEDs illuminated: 50 % capacity 1 LED fl... -
Page 6: Jaw Replacement
2.8) ”W” style crimping dies assembles – Press pins (2) and insert “W” dies into their seats (see Fig. 4). – To disassemble them simply press the pins and slip them from the jaws. T IS RECOMMENDED TO USE THE TOOL ONLY WITH PRODUCT TO BE CRIMPED INSERTED FIG. -
Page 7: Maintenance
Centre; if pos- sible, attach a copy of the Test Certifi cate supplied by Cembre together with the tool or, if no other references are available, indicate the approximate purchase date and the tool serial number. -
Page 8: User Information
Unlawful disposal of such equipment will be subject to the application of admin- istrative sanctions provided by current legislation. SPARE PARTS LIST Cembre The guarantee is void if parts used are not original spares. When ordering spare parts always specify the following:... - Page 9 CDD6 jaw TABLE 2 Item Code N° DESCRIPTION 6000577 BODY RIGHT+LEFT SHELL 6000128 BATTERY ADAPTER SHELL R+L 2598495 BATTERY CB1820L Li-Ion 18V 2Ah 6000217 OPERATING BUTTON 6000127 SHUTTER 6000591 6000593 SPRING 6000150 CONTACT SUPPORT 6000218 PRESSURE RELEASE BUTTON 6000582 BUTTON STRIKER 6000200 MECHANICAL GROUP 6004168...
- Page 10 See TABLE 3...
- Page 11 TABLE 2...
- Page 12 TABLE 3 (ITEM 11 IN TABLE 2) Code N° Item DESCRIPTION 6000625 RUBBER GRIP 6000199 ACTUATING MECHANICAL GROUP 6000357 HOUSING 6000358 GEAR 6760004 Ø 2X8 CYLINDRICAL PIN 6900008 M3x6 SCREW 6000849 Ø 3 SCHNORR WASHER 6740020 1/4" BALL 6000363 GEAR 6402009 BEARING 6402006...
- Page 13 TABLE 3 (ITEM 11 IN TABLE 2) Item Code N° DESCRIPTION 6520200 SPRING 6740120 7/32" BALL 3041735 6640205 D. 4 SCHNORR WASHER 6900052 M4x6 SCREW 6000602 LEVER SPRING 6900054 M4x6 SCREW 6360022 O-RING 6360125 O-RING 6641020 Ø 6 CU WASHER 6000318 SPRING GUIDE 6160081...
- Page 15 TABLE 3 (ITEM 11) TIGHTENING TORQUE COUPLE DE SERRAGE DREHMOMENT PAR DE TORSION COPPIA DI SERRAGGIO 8 Nm (5.9 lbf ft)
- Page 16 CS 92014 – 91423 Morangis Cédex E-mail: sales@cembre.com E-mail: sales@cembre.co.uk E-mail: info@cembre.fr www.cembre.it www.cembre.co.uk www.cembre.fr Cembre España S.L.U. Cembre GmbH Cembre Inc. Calle Verano, 6 y 8 - P.I. Las Monjas Heidemannstraße 166 Raritan Center Business Park 28850 Torrejón de Ardoz - Madrid (España) 80939 München (Deutschland)
