Connect Tech - Xtreme/Multi-I/O - Users Guide
Typical programming sequence:
CFG?
Xtreme/Multi-I/O Configuration
Firmware Version V1.00
FPGA Version A
Decode IO region is 10 bits
U1
U1P1 = (IO) 0x0300, 10
U1P2 = (IO) 0x0308, 10
U1P3 = (IO) 0x0310, 10
U1P4 = (IO) 0x0318, 10
U2
U2P1 = (IO) 0x0320, 10
U2P2 = (IO) 0x0328, 10
U2P3 = (IO) 0x0330, 10
U2P4 = (IO) 0x0338, 10
Uart Clock Setting = Mode 3 (1.8432MHz)
Uart 1 is ENABLED
Uart 2 is ENABLED
Uart 3 is ENABLED
Uart 4 is ENABLED
Uart 5 is ENABLED
Uart 6 is ENABLED
Uart 7 is ENABLED
Uart 8 is ENABLED
Port 5 termination enable/disable setting = T
Uart 1 DTR/DSR wrapback is CONNECTED
Uart 2 DTR/DSR wrapback is CONNECTED
Uart 3 DTR/DSR wrapback is CONNECTED
Uart 4 DTR/DSR wrapback is CONNECTED
Uart 5 DTR/DSR wrapback is CONNECTED
S1R?
Socket 1 RESET = NO
S2R?
Socket 2 RESET = NO
C1?
CAN1 = (IO) 0x0000, 255
CAN1 is DISABLED
C2?
CAN2 = (IO) 0x0000, 255
CAN2 is DISABLED
CM?
BASIC
Port 5 mode of operation set to J1708_MODE
Board base = (IO)
CAN clock rate is currently set to 24MHz
J?
J1708 = (MEM) 0x00ff80, 255
Temperature is 301.65 K (28.50 C)
OK
DIS?
Invalid Command
RS8=D
OK
RS8?
Uart 8 is DISABLED
OK
SER?
SER
U1P1 = (IO) 0x0300, 10
U1P2 = (IO) 0x0308, 10
U1P3 = (IO) 0x0310, 10
U1P4 = (IO) 0x0318, 10
U2P1 = (IO) 0x0320, 10
U2P2 = (IO) 0x0328, 10
U2P3 = (IO) 0x0330, 10
U2P4 = (IO) 0x0338, 10
OK
UPD
OK
