Quick Start Manual

Advertisement

   Related Manuals for Epson 1680

   Summary of Contents for Epson 1680

  • Page 1

    Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product.

  • Page 3: Where To Find Information

    Online help for EPSON TWAIN Pro and EPSON TWAIN Pro Network Online help provides you with detailed information on EPSON TWAIN Pro and EPSON TWAIN Pro Network. To access online help, click the Help button in EPSON TWAIN Pro or EPSON TWAIN Pro Network.

  • Page 4: Table Of Contents

    Contents ENERGY STAR® Compliance ........5 Warnings, Cautions, and Notes .

  • Page 5: Energy Star® Compliance

    ® NERGY Compliance ® As an NERGY Partner, EPSON has determined that this product meets the ® NERGY guidelines for energy efficiency. ® The International NERGY Office Equipment Program is a voluntary partnership with the computer and office equipment industry to promote the introduction of...

  • Page 6: System Requirements

    Before installing the scanner software, make sure that your system meets the following requirements. When connecting the scanner directly to your computer For Windows SCSI users Scanner: EPSON Expression 1680/Expression 1680 Pro ® System: Microsoft Windows Millennium Edition, Windows 98, Windows 95, Windows 2000, or Windows NT 4.0...

  • Page 7

    For Windows USB users Scanner: EPSON Expression 1680/Expression 1680 Pro System: Microsoft Windows Millennium Edition, Windows 98, or Windows 2000 pre-installed Interface: USB port (Type A receptacle) VGA or higher resolution monitor 640 × 480 screen resolution Display: (800 × 600 or higher recommended), and 65,000 colors (or...

  • Page 8: When Scanning Over A Network

    For Macintosh USB users Scanner: EPSON Expression 1680/Expression 1680 Pro System: Apple Macintosh PowerPC with built-in USB ports and running Mac OS 8.5 or later iMac running Mac OS 8.5 or later Interface: USB port Note: You cannot use a serial interface.

  • Page 9: Unpacking The Scanner

    10BaseT/100BaseTX, 10Base5, 10Base2 Ethernet communication TCP/IP protocol: Unpacking the Scanner Your Expression 1680/Expression 1680 Pro comes shipped with CD-ROMs which include the driver software that runs your scanner, and some additional items, depend- ing on your scanner model. scanner power cord...

  • Page 10

    Note: The Transparency Unit that comes standard with the Expression 1680 Pro is also available as an option for the Expression 1680. Depending on the country of purchase, the power cord may come attached to the scanner.

  • Page 11: Scanner Parts

    Scanner parts document cover carriage (in the home position) document table ERROR light start button READY light operate button option interface connector transportation lock lever SCSI ID rotary switch SCSI terminator switch USB interface connector SCSI interface connectors AC inlet optional interface slot...

  • Page 12: Setting Up The Scanner

    Setting Up the Scanner Choosing a place for the scanner Follow the guidelines below when selecting a location for your scanner. Place the scanner on a flat, stable surface. The scanner will not operate properly if it is tilted at an angle. Place the scanner close enough to the computer for the interface cable to reach it easily.

  • Page 13: Plugging In The Scanner

    2. Slide the transportation lock lever on the back of the scanner to the UNLOCK position, as shown below. Note: Simply sliding the transportation lock to the LOCK position does not fully lock the carriage. Before moving or transporting the scanner, be sure to perform the procedure under “Transporting the Scanner and the Transparency Unit”...

  • Page 14: Checking Initialization

    Checking initialization Before connecting the scanner to your computer, follow the steps below to make sure that the scanner initializes, or starts up, properly. 1. Open the document cover so you can see the operation of the scanner during initialization. 2.

  • Page 15

    For PC users: Unless your PC already has a SCSI board installed, you need to install one, along with SCSI driver software. Install the SCSI board according to the directions included with it. Also see "Installing a SCSI interface board" in your online Setup Guide. Note: You will also need to install the SCSI driver that is normally included with Windows (see your Windows documentation for instructions), or the driver described in your...

  • Page 16

    If you add the scanner to a system in which one of your SCSI devices already has a SCSI ID of 2, change the ID number to an unused number using the rotary switch. See the table below as a guide. Availability Description Not available for Macintosh...

  • Page 17: Setting The Terminator Switch

    Setting the terminator switch The scanner has a built-in terminator, which allows SCSI devices to communicate properly with each other. Depending on your computer system, you may need to change the terminator switch setting. Note: Do not use an external terminator. The terminator switch is located at the rear of the scanner.

  • Page 18

    Connecting the scanner Connect the scanner to your computer or to another SCSI device as described below. Note: The types of connectors needed on the SCSI interface cable varies depending on the maker of your SCSI device and SCSI interface board. 1.

  • Page 19: Connecting The Scanner Using The Usb Interface

    Power-on sequence Always turn on your scanner or other SCSI devices before turning on the computer. If your scanner is connected to a daisy chain, turn on the SCSI device which is connected at the farthest end of the chain first, then proceed to the second farthest device and so on before turning on your computer.

  • Page 20

    In this case, try connecting the scanner directly to the computer’s USB port. Also, your system may not work properly if you use a USB cable other than that supplied by EPSON. Connecting the scanner Follow these steps to connect the scanner to your computer or USB hub.

  • Page 21

    In this case, see the EPSON TWAIN Pro installation instructions in Chapter 3 of the online Setup Guide to complete the setup procedure.

  • Page 22: Using The Online Manuals

    Start Button feature. Reference Guide Provides tips for optimizing scanning and detailed information on the settings and functions of EPSON TWAIN Pro and EPSON TWAIN Pro Network. Also explains how to modify the operation of the scanner’s Start button.

  • Page 23: Accessing The Online Manuals

    Before you can access the online manuals from your hard disk, you first have to install them on the hard disk. 1. Insert the EPSON Online manual CD-ROM into your computer’s CD-ROM drive. Windows: The setup program on the CD-ROM will be started automatically and displays the start screen.

  • Page 24: Customer Support

    Once the manuals have been installed on the hard disk, proceed as follows: Click the Start button, point to Programs, then point to EPSON. Click on the name of an online manual. The Acrobat Reader will be started automatically and the online manual opened.
