Getting Started
Attaching the Belt Clip to
your Phone
The phone is delivered with the standard
belt clip.
To attach the belt clip to your phone:
1. Slide the metal part of the clip into
the molded slot on the back of the
phone until it snaps into place. See
Figure 3.1.
2. Tighten the retention screw to
secure the belt clip onto your phone.
See Figure 3.2
Figure 3.1
Retention Screw
Figure 3.2
Removing the Belt Clip from
your Phone
1. Untighten the retention screw of
the belt clip from the phone (see
Figure 3.2).
2. Slide the metal clip upward in the
slot as shown in Figure 3.3.
Figure 3.3
