REPAIR KITS ___________________________________________________________________________________________

DESCRIPTION
START UP AND
MAINTENANCE KIT
GASKET KIT
COMPLETE PUMP
VALVE KIT
PISTON RING KIT
http://air.irco.com
PART NO. KIT CONTENTS
42661561 (1) LITER OF OIL — PART NO. 38436721
(2) INLET FILTER COMPLETE — PART NO. 70243399
42665463 (2) CYLINDER GASKET — PART NO. 23191901
(1) REAR BEARING SEAT GASKET — PART NO. 23192016
(2) CYLINDER HEAD GASKET — PART NO. 23192040
(2) VALVE SEAT GASKET — PART NO. 23213051
42660597 ALL PARTS IN "PUMP COMPONENTS" ILLUSTRATION, COMPLETELY ASSEMBLED.
23191877 (2) CYLINDER HEAD GASKETS — PART NO. 23192040
(2) IN. & EX. VALVE ASSEMBLY — PART NO. 23213044
(2) VALVE SEAT GASKETS — PART NO. 23213051
42665950 (2) CYLINDER GASKETS — PART NO. 23191901
(2) PISTON RING SETS — PART NO. 23191919
10
P1.5IU-A9
