Operating & Maintenance Manual
P600WIR (7/170), HP450WIR (10/125),
This manual contains important safety information.
Do not destroy this manual.
This manual must be available to the personnel who operate and maintain this machine.
P.O. Box 868 - 501 Sanford Ave
Mocksville, N.C. 27028
Book 22442594 (1/07)
Revised (10-12)
Compressor Models
VHP400WIR (14/115)
Code:
Doosan purchased Bobcat Company from Ingersoll-Rand Company in
2007. Any reference to Ingersoll-Rand Company or use of trademarks,
service marks, logos, or other proprietary identifying marks belonging
to Ingersoll-Rand Company in this manual is historical or nominative
in nature, and is not meant to suggest a current affiliation between
Ingersoll-Rand Company and Doosan Company or the products of
either.
