LIVE VIEW / SNAPSHOT / VIDEO RECORD
Main page
System Name & View Mode
Connection Status
Video Resolution
Snapshot
Function
System Name & View Mode Display the name of the camera assigned by user and current
Connection Status
Video Resolution
Camera Mode
Snapshot
Video Record
Return
Description
view mode (Live-View or Playback).
Indicating the connection status (Connected or Disconnected)
between the app and the camera.
Indicating the video resolution, either VGA (640*480) or HD
(1280*720)
Battery Mode - power by battery, camera on only
Battery
after detects motion to conserve battery power.
USB Mode - power by adaptor, camera always on
USB
for anytime remote view.
Tap icon to take snapshot(s). Captured images are stored in the
mobile device.
Tap icon to manually start recording. Each recording session
will last for 5s, 10s, 15s or 30s and cannot be stopped during
the recording period. Captured videos are stored in the memory
card of the camera.
Tap icon to return to the main page (device list).
15
Battery
Camera Mode
Video Record
Return
