ALC AWSC35 Quick Start Manual

PRINTED ON A4 SIZE SHEET (8.25X11.69") folded in half
BACK cover
ATOMS LABS, LLC
CUSTOMER SUPPORT 9:00 am - 6:00 pm (Central Time)
2670 Firewheel Drive, Suite D
1.844.767.8544
Monday - Friday
Flower Mound, TX 7502
FO LD
Front cover
Wireless Outdoor
Security Camera
ACCESSORY
Compatible with ALC AWS3155 and AWS3266
Video Surveillance Systems
Model AWSC35
QUICK START GUIDE
Wireless Made Simple.
FO LD
INTERIOR
Let's Get Started
Indoor/Outdoor Camera
IN THE BOX
Outdoor camera with
multi-position stand
Antenna
AC power adapter
AC Power cord
Camera
Bracket T-Bolt
Power extension cable
Thumb screw
In-line Pairing
Multi-position
Button
Camera Bracket
Camera Installation
Screw Pack
Tip:
Plan the location of your camera for optimal viewing and proximity to AC Power outlets, (1) power extension
cable is included.
Quick Start Guide
NOTE: Avoid installing in a location which requires the Wireless signal to pass through cement, concrete and metal
structures. This will reduce the transmission range.
CAMERA INSTALLATION + SETUP
CAMERA MOUNTING
Secure the multi-position Loosen the T-Bolt on the camera Align hole on bottom of camera
1 2 3
camera stand to a stable stand and adjust viewing angle using with T-Bolt to install camera.
surface, ceiling or wall. the Thumb Screw to rotate position. Screw antenna into rear of camera.
11.69"
REQUIRES ALC AWS2155 WIRELESS SURVEILLANCE SYSTEM TO WORK.
Model AWSC35
PAIRING ADDITIONAL
CAMERAS TO MONITOR
The Wireless Surveillance System supports up to four (4)
wireless surveillance cameras. Use the following steps to pair
each additional camera.
Infrared
LED sensors
Camera In-line
AC power cable
Pairing Button
From the Main Menu on the Monitor, select the
CAMERA SET UP icon
Select camera
station to
be paired
Tap the CAMERA STATION you want to pair;
a 60-second timer will start.
2
Within 60 seconds, press the PAIRING KEY once on the camera's
power cord or in the back of the camera. The timer will stop when
the camera is paired.
3
Go to Home Screen to view live cameras on the Monitor.
NOTE: Cameras are IP66 rated for indoor/outdoor use. For outdoor use it is
recommended to install camera under shelter to protect from direct exposure to
sunlight and other environmental elements. Avoid pointing a camera directly at
any bushes or tree branches or objects that may naturally move due to winds.
For detailed installation and setup, please refer to the Model AWSC35
extended User's Guide available on our website:
www.atomslabs.com/support
Attach power cable to power
4
SCAN
extension cord AC Adapter.
TO VIEW COMPLETE USER'S GUIDE
Plug into electric outlet.
