ALC AWF13 Quick Start Up Manual

CAMERA INSTALLATION + SETUP
CAMERA INSTALLATION
1 Screw the Antenna clockwise 2 Secure the multi-position Camera Bracket to a stable
into the rear of the camera. surface, ceiling or wall using the two screws. If
needed, two anchors are also included. Secure the
camera to the Camera Bracket using the three smaller
screws.
NOTE: Avoid pointing a camera directly at any bushes or tree branches or objects that may naturally move due to winds.
3 Connect the small end of the AC 4 Plug into electrical outlet when
adapter to the camera's AC In jack. ready to install App (Step 2 in
REMOTE VIEWING section).
Recommendations for best system performance:
• iOS 6.0 or above.
• Android: Android smartphone or tablet (version 2.3x or above). TM
• Storage: Class 10 microSD memory card (up to 32 GB).
• Bandwidth: 512Kbps or above upload/download speed suggested.
BACK cover
FO LD
720p Indoor
Pan/Tilt Wi-Fi
Camera
Model AWF13
QUICK START GUIDE
Wireless Made Simple.
Front cover
APPLE REMOTE VIEWING
APPLE DEVICE SETUP
SightHD
1
From your smart device, DOWNLOAD and INSTALL the free ALC SightHD App.
2
Plug camera into an electrical outlet (allow the camera up to 90 seconds to boot up).
3
On your Apple device, open the Settings App. Tap Wi-Fi and under Choose A Network, select the HD-XXXXXX Network.
4
When asked for a password, enter, "12345678". Tap Join to connect.
FREE APP DOWNLOAD
5
Now Launch the ALC SightHD App and the Setup Wizard will appear.
6
Tap " " to start the Wizard.
7
Once the screen indicates the camera is connected, tap Live View.
8
Once the camera is found, the screen will show a Live View briefly before moving to a set up screen.
9
At the next screen enter a new password and remember it or write it down. Tap Wi-Fi Setting.
10
Select your home network from the menu, and then enter your home network's Wireless Password. Tap OK.
11
The system will reboot the camera. The reboot will be complete when the App finishes counting down from 90.
Tap still image for live video.
ANDROID REMOTE VIEWING
ANDROID DEVICE SETUP
1 From your smart device, DOWNLOAD and
INSTALL the free ALC SightHD App.
SightHD
2
Plug camera into an electrical outlet (allow the
camera up to 90 seconds to boot up).
3 Tap Set Up Wizard on screen for direct wireless
connection of camera to App.
4 Tap Next.
5
The App will start the connection process. Tap Live View.
6
Smart device will scan and detect camera. Once found,
the Change Password screen will appear. Enter a password
and remember it or write it down for future use. Tap OK.
FREE APP DOWNLOAD
7 The Setup Wi-Fi Network pop up box will appear. Select your
home network from the menu, and then enter your home
network's Wireless Password. Tap OK. The App will reboot
the camera. Tap image for live video.
NOTE: Screen shots and icons may vary due to continuous updates to App and software development.
LIVE VIEW RECORDING
PLAYBACK
on microSD CARD*
1
1 Tap CAMERA SETTING icon and then EVENT LIST icon
Insert a microSD card into the rear of camera.
NOTE: For Apple devices tap the Search icon to bring up the Events screen.
2
Select the Start and Stop date and time on the Select Event Filter and tap OK.
microSD Card Slot*
3
Tap the FILE that you want to playback from the list.
*microSD card (not included) is
required to record video to camera.
2
Manually RECORD video from Live View by
tapping Record icon. Recording will stop
after approximately two minutes.
Motion Recording
To set MOTION ACTIVATED RECORDING,
Go to Advanced Settings in App >
SENSITIVITY SETTINGS to select options.
The Advanced Settings will ask for the
admin password, default password is:
123456. You can change the default
password within the Advanced Settings.
NOTE: Do not submerge camera in water. STRANGULATION HAZARD: Infants have STRANGLED in power cords. Keep power cords For detailed installation and setup, please refer to the
more than 3 feet away from cribs. When using your equipment, always follow basic safety precautions to reduce the risk of fire,
Model AWF13 complete User's Guide available on our website:
electric shock and injury to persons. Illustrations are for reference only. Actual product specifications may vary.
www.ALCWireless.com/support
For additional precautions and product information, please see owner's manual at www.ALCWireless.com/support
Wireless
Made Simple.
ALCWireless.com
