- Page 1 720p Outdoor Wi-Fi Camera Model AWF50 User Guide Please read these instructions completely Wireless Made Simple. before operating this product.
-
Page 3: Table Of Contents
Requirements For Remote View ..................10 Connecting to the Internet ....................11 Connecting Via the Android App ..................12 Connecting Via the Apple App ..................14 ALC SightHD App Icons ....................20 To Take Snapshots ......................22 To View and/or Take Videos ....................24 Motion Recordings ......................25 To Play Videos .........................26... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS PRODUCT SAFETY: When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. Improper use of this product can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these instructions handy for future reference. - Page 5 IMPORTANT SAFETY INSTRUCTIONS WARNING: STRANGULATION HAZARD: Infants have STRANGLED in power cords. Keep power cords more than 3 feet away from cribs, bassinets, play yards, and other safe sleep environments for infants. IMPORTANT SERVICE SAFETY INSTRUCTIONS Damages caused by non-compliance with this operating manual will void the warranty! Read and Follow Instructions - All the safety and operating instructions should be read before the product is operated.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS 10. Attachments - Do not use attachments unless recommended by the product manufacturer as they may cause a hazard. 11. Water and Moisture - Do not use receivers or video monitors near water — for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, near a swimming pool and the like.
-
Page 7: Introduction
INTRODUCTION System Contents After unpacking, you will have the following items: Camera AC Adapter Antenna Camera Bracket Extension Cable 720p Outdoor Wi-Fi Camera Model AWF51 Quick Start Guide Please read these instructions completely Wireless Made Simple. before operating this product. Screw/Anchor Kit Quick Start Guide MicroUSB to RJ-45 Cable... -
Page 8: Getting To Know Your Camera
INTRODUCTION Getting to Know Your Camera FRONT Power Status Link Status Passive Infrared Sensor Mounting Socket REAR Antenna Power Connector Pigtail Microphone microSD Slot — 6 —... -
Page 9: Installation
INSTALLATION Installation Tips WARNING: Weatherproof, IP66 rated cameras are suitable for outdoor installation. However, if possible, it is recommended to install in a location that provides some shelter from the elements, such as beneath roof eaves. • Before you install the camera, plan where and how it will be positioned, and where you will route the cable that connects the camera to the power adapter. -
Page 10: Installing The Camera
INSTALLATION Installing the Camera IMPORTANT: Please set up the camera first before mounting; please stay in close range with the camera during setup. If not mounting, but just using on a flat surface (desk, table, etc.), skip to step 4. Secure the multi-position Camera Bracket to a stable surface, ceiling or wall using the three screws. - Page 11 INSTALLATION Installing the Camera Screw Antenna clockwise into rear of camera. To record videos you must insert a microSD card, not included. The microSD Slot is located under the flap on the rear of the camera. microSD Slot Connect one end of an AC adapter to the camera’s power pigtail and plug the other end of the adapter to a 120 volt AC (standard indoor) power outlet.
-
Page 12: Remote Access
REMOTE ACCESS Overview This camera allows you to view live video from an iPhone , iPad , iPod Touch or Android ® ® ® smartphone or tablet. Free apps are available through the Apple App Store or the Android Market/Google Play. Up to three remote users can access live video at the same time as long as they have the User ID (DID) Code and Security Code. -
Page 13: Connecting To The Internet
Download the ALC SightHD App as follows: APPLE DEVICE: From your iPhone or iPad, go to the App Store and search for ALC SightHD. ANDROID DEVICE: From your Android smartphone or tablet device, go to Google Play and search for ALC SightHD. -
Page 14: Connecting Via The Android App
(allow the camera up to 90 seconds to boot up). When the green Link Status indicator begins blinking, the camera is ready to be set up. Launch the ALC SightHD App and the Setup Wizard screen will appear. Tap “+” to start the Wizard. Tap Next. - Page 15 REMOTE ACCESS Connecting Via the Android App You will then be requested to change your password if this is the first time accessing the camera. Enter a password and remember it or write it down for future use. Tap OK. The Setup Wi-Fi Network pop up box will appear.
-
Page 16: Connecting Via The Apple App
REMOTE ACCESS Connecting Via the Apple App Plug camera into an electrical outlet and the red Power Status indicator will light (allow the camera up to 90 seconds to boot up). When the green Link Status indicator begins blinking, the camera is ready to be set up. - Page 17 REMOTE ACCESS Connecting Via the Apple App When asked for a password, enter, “12345678”. Tap Join to connect. Now Launch the ALC SightHD App and the Setup Wizard screen will appear indicating the setup instructions. Tap “+” to start the Wizard.
- Page 18 REMOTE ACCESS Connecting Via the Apple App The Apple Device will now search for the camera. Once the screen indicates the camera is connected, Tap Live View. ‘HD-000011’ has been connected. — 16 —...
- Page 19 REMOTE ACCESS Connecting Via the Apple App The Apple device will scan and detect the camera. Once found, the screen will show a Live View briefly before moving to a set up screen. You will then be requested to change your password if this is the first time accessing the camera.
- Page 20 REMOTE ACCESS Connecting Via the Apple App The system will reboot the camera, please give it up to 90 seconds, until the App finishes the count down from 90. Tap still image for live video. If camera does not connect, tap Reconnect icon.
- Page 21 REMOTE ACCESS ALC SightHD App Icons Main Screen The following icons appear when on the Main screen. Tap the arrows to access the live video screen. If you have already selected a view and go back to the previous screen (arrows screen) a still picture of the live video appears instead.
-
Page 22: Alc Sighthd App Icons
REMOTE ACCESS ALC SightHD App Icons Icon Icon Description Add System Tap this icon to enter the setup wizard; see page 12. Camera Setting Tap this icon to access the App’s options. See below: Tap this icon to set up camera configuration or make changes to your existing settings. - Page 23 REMOTE ACCESS ALC SightHD App Icons Icon Icon Description Capture Tap to capture screen images. The snapshots will be saved into the camera roll of your mobile device. See page 22 for more details. Record Tap to record and tap again to stop recording.
-
Page 24: To Take Snapshots
REMOTE ACCESS To Take Snapshots From the Main screen, tap to remote view your camera system. If you’ve accessed live video previously, a still picture will appear instead of the arrows. Tap the Capture icon to take a snapshot of the current image; “Snapshot is successful”... - Page 25 REMOTE ACCESS To Take Snapshots PINCH AND ZOOM: To zoom in or out, use the simple pinch and zoom gesture with this app. — 23 —...
-
Page 26: To View And/Or Take Videos
REMOTE ACCESS To View and/or Take Videos From the main screen, tap to remote view your camera system. If you’ve accessed live video previously, a still picture will appear instead of the arrows. Tap the Record icon to start recording, “Device Recording”... -
Page 27: Motion Recordings
REMOTE ACCESS To View and/or Take Videos PINCH AND ZOOM: To zoom in or out, use the simple pinch and zoom gesture with this app. Motion Recordings When motion is detected on the video camera, the camera will automatically record for two minutes and then stop recording. -
Page 28: To Play Videos
REMOTE ACCESS To Play Videos From the main screen, tap the Settings icon. Tap the Events icon; the “Select Event Filter” pop-up will appear. For Apple, see note below. APPLE: You must tap the Search (Magnifying glass) icon to bring up the Event’s screen. - Page 29 REMOTE ACCESS To Play Videos Select the desired Start Time/Date of the videos you want to view by tapping on the respective option (date or time) and then tapping “+” or “-” to adjust. When finished, tap Done. Repeat for Stop Time/Date, then tap OK;...
- Page 30 REMOTE ACCESS To Play Videos Tap the video name once to play the video clip. When playing back a video, tap the Pause icon to pause the video. Tap again to resume. PINCH AND ZOOM: To zoom in or out, use the simple pinch and zoom gesture with this app;...
-
Page 31: To Delete Videos
REMOTE ACCESS To Delete Recordings Access the Events List as shown on pages 26 and 27. Tap the Edit Icon. ANDROID: Select the file you wish to delete (a check mark will appear in the box to the right of the selected file) then tap the Delete Selected icon. - Page 32 REMOTE ACCESS To Delete Recordings To delete all files, tap the Delete All icon. A pop-up box will appear asking you to confirm; tap Yes. — 30 —...
-
Page 33: Information Screen Options
REMOTE ACCESS Information Screen Options From the main screen, tap the Information icon; a pop-up will appear. To view information (Version, etc.), tap About. — 31 —... - Page 34 Launch Settings/System Preferences from your Home screen on the Apple device. Tap Notification Center; a list of Apps will appear. Scroll down to find “ALC SightHD” App and click on it. The Setting screen displays. Turn the notification ON or OFF as desired.
- Page 35 REMOTE ACCESS Information Screen Options To Setup the Pin Lock, tap Setup PIN Lock. TIP: Setting a PIN Lock code will prevent others from activating the app and viewing your camera images. Tap the Enable Lock When Starting switch to enable (will be blue), or disable (will be white) the PIN Lock.
- Page 36 REMOTE ACCESS Information Screen Options Using the keyboard, enter a four digit code. Then confirm this exact code. Now that the Pin is set and enabled, whenever the App is opened you must enter this code. — 34 —...
-
Page 37: Did Setting Screen
REMOTE ACCESS DID Setting Screen From the main screen, tap the Settings icon. Tap the Settings icon; the System Information Screen will appear. — 35 —... - Page 38 REMOTE ACCESS DID Setting Screen Simply tap on a field to change it. To enable Email Alert, which will email your Gmail account whenever motion is detected, simply tap the Enable Email Alert switch so it is blue. — 36 —...
- Page 39 REMOTE ACCESS Advanced Settings From the main screen, tap the Settings icon. Tap the Settings icon; the System Information Screen will appear. — 37 —...
-
Page 40: Advanced Settings
REMOTE ACCESS Advanced Settings Tap on the Advanced Settings icon. Enter your Admin password (Default was 123456 unless it was changed), then tap OK. — 38 —... - Page 41 REMOTE ACCESS Advanced Settings The following screen will appear. Scroll on the device to view the lower options. Perform the following on this screen: ADMIN PASSWORD: Tap to change the Admin Password from the default 123456. Admin Password is used to get into this screen. TIME ZONE: Tap to change/set the Time Zone where the camera is located.
- Page 42 REMOTE ACCESS Advanced Settings SENSITIVITY SETTINGS: Tap to set the desired Sensitivity Settings as follows: Off: Turns sensitivity off. PIR (Passive Infrared Sensor): This technology measures infrared light emitted from objects that generate heat. Selecting this option will increase the chance of humans and animals activating the motion sensor, while blowing curtains or insects will not.
-
Page 43: Maintenance
MAINTENANCE Cameras When dust and grime builds up on the camera lens and glass, it will affect the night vision capability. The infrared light reflects off of the dust and grime, limiting the camera’s “vision.” Use a microfiber cloth to regularly clean the camera or when night vision video is cloudy or unclear. —... -
Page 44: Troubleshooting
TROUBLESHOOTING If you have any trouble with your system, try these simple steps which should handle most common issues. Problem Possible Solution Make sure the camera’s power is on. Make sure your network supports DHCP protocol. Make sure the camera and mobile device are on the The App cannot locate the camera. -
Page 45: Factory Default/Reset
TROUBLESHOOTING Problem Possible Solution The camera’s infrared LEDs shine invisible light that reflects off of surfaces such as glass and will cause white A white image appears at light. Place the camera on the other side of the window night. to improve the night vision or place it in a well-lit area (recommend to install a security lamp to improve lighting). -
Page 46: Product Specifications
PRODUCT SPECIFICATIONS Camera Communication Range ............500 ft (164 yards) in open space Camera Resolution Single Camera ................1280x720 Operating Temperature ...............14°F ~ 122°F (-10°C ~ 50°C) Operating Voltage ....................DC 5V, 1.5A Current Consumption ..................500 mA (MAX) Night Vision ........................35 ft Dimensions .............. -
Page 47: Warranty
ALC service center for a defect or malfunction covered by this warranty, (E) used in any conjunction with equipment or parts or as part of any system not manufactured by ALC, or (F) installed or programmed by anyone other than as detailed by the owner’s manual for this product. - Page 48 PROCEDURE FOR OBTAINING PERFORMANCE OF WARRANTY: If, after following the instructions return it to you without charge for parts, service, or any other cost. ALC, at its option, may replace the unit with a new or in the owner’s manual you are certain that the Product is defective, pack the Product carefully refurbished unit.
- Page 49 Wireless Made Simple. ALCWireless.com 012016_v1.1...
- Page 50 Wireless Made Simple. ALCWireless.com...
