- Page 1 COOPER POWER Padmounted Switchgear SERIES Effective May 2017 MN285018EN Supersedes October 1994 (S285-80-1) DC motor operator control installation and operation instructions...
- Page 2 CONTENTS OF THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT BETWEEN THE PARTIES. In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or other-wise for any special, indirect, incidental or consequential damage or loss whatsoever, including but not limited to...
-
Page 3: Table Of Contents
Contents DISCLAIMER OF WARRANTIES AND LIMITATION OF LIABILITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . I SAFETY FOR LIFE . -
Page 4: Safety For Life
FOR LIFE FOR LIFE Eaton’s Cooper Power series products meet or exceed all applicable industry standards relating to product safety. We actively promote safe practices in the use and maintenance of our products through our service literature, instructional training programs, and the continuous efforts of all Eaton employees involved in product design, manufacture, marketing, and service. -
Page 5: Product Information
Quality standards Service Information MN285018EN provides installation and ISO 9001 Certified Quality Management System. operating instructions for Eaton’s Cooper Power series DC Motor Operator control. Before installing and operating this Control battery storage and charging control, carefully read and understand the contents of this The 24 Vdc control battery is fully charged prior to manual. -
Page 6: Control Power
For these applications, an optional The DC motor operator control is designed for use interface, separate from the control, can be additionally with Eaton’s Cooper Power series Type RVAC and VFI provided (consult factory for details). pad-mounted switchgear. The motor operator control is applicable with both 600 amp vacuum loadbreak switch mechanisms and vacuum fault interrupter mechanisms. -
Page 7: Control Operation-Local Mode
DC motor operator control installation and operation instructions Control operation-local mode OPEN (GREEN PUSH BUTTON)e: Opens the selected switch or interrupter mechanism, via the motor operator. The operator panel is located inside, and at the top, of the control cabinet. The operator panel contains the power STOP (YELLOW PUSH BUTTON)e: Stops the motor- toggle switch, the SCADA toggle switch, the motor select operated opening or closing action of the selected switch or... -
Page 8: Wiring Schematic
DC motor operator control installation and operation instructions Figure 4 . Wiring schematic of DC motor operator control OPERATION INSTRUCTIONS MN285018EN May 2017... - Page 9 DC motor operator control installation and operation instructions This is a typical schematic diagram for standard Motor Operator Control. Refer to the schematic diagrams supplied otee: with your control for specific information on accessories or special modifications that were supplied at the time of manufacture.
-
Page 10: Instructions For Local Mode Operation
DC motor operator control installation and operation instructions Instructions for LOCAL mode operation Features available through SCADA terminals: For DC Motor Operator Control wiring and outline Select one of several motors. ● ● information, refer to Figure 5 and 8. Read status of selected motor. -
Page 11: Extended Control Accessory
DC motor operator control installation and operation instructions Control operation – extended control With the DC Motor Operator Control SCADA toggle switch set to LOCAL and the rotary MOTOR SELECT switch set to the OFF position, the operation capabilities from the extended control accessory are: Select one of several motors. -
Page 12: Outline Diagram
DC motor operator control installation and operation instructions Figure 7 . Outline diagram of DC motor operator control OPERATION INSTRUCTIONS MN285018EN May 2017... -
Page 13: Scada Terminal Block Connection Procedures
DC motor operator control installation and operation instructions SCADA Terminal block connection procedures The DC motor actuator can be manually disconnected by removing the cotter pin which connects the motor to the SCADA terminal block connection can be completed via yellow handle (See Figure 11). -
Page 14: Maintenance Information
Service Department. To order maintenance record log. Refer to Tables 1 and 2 for typical parts, contact your Eaton representative for additional operating characteristics of the DC Motor Operator Control. information and ordering procedures. - Page 15 DC motor operator control installation and operation instructions This page intentionally left blank. OPERATION INSTRUCTIONS MN285018EN May 2017...
- Page 16 Waukesha, WI 53188 United States Eaton.com/cooperpowerseries © 2017 Eaton All Rights Reserved Printed in USA Eaton is a registered trademark. For Eaton’s Cooper Power series product Publication No. MN285018EN information May 2017 call 1-877-277-4636 or visit: All trademarks are property www.eaton.com/cooperpowerseries.
