Specifications - Icom IC-E90 Service Manual

Multiband
Hide thumbs Also See for IC-E90:

Advertisement

SECTION 1
M
GENERAL
• Frequency range
Version
50 MHz
EUR
50 – 52
UK
ITR
50 – 51
ESP
EUR-1
FRA
50.2 – 51.2
• Mode
• Number of memory channels
• Frequency stability
• Tuning steps
• Usable tempareture range
• Power supply requirement
• Usable battery pack/case
• Polarity
• Current drain (at 8.0 V DC) : (typical value)
• Anntena connector
• Dimensions (projections not included) : 58(W) × 87(H) × 29(D) mm; 2
• Weight (with BP-217/Ant.)
M
TRANSMITTER
• Output power
(at 8.0 V DC)
• Modulation system
• Max. freq. deviation
• Spurious Emissions
• External MIC connector

SPECIFICATIONS

:
145 MHz
440 MHz
430 – 440
430 – 434
435 – 438
144 – 148
430 – 440
: FM, AM (RX only) and WFM (Rx only)
: 555 (incl. 50 scan edges and 5 call channels)
: ±6 ppm max.
–10˚C to +60˚C; 14˚F to 140˚F)
(
: 5, 6.25, 8.33, 9, 10, 12.5, 15, 20, 25, 30, 50 100, and 200 kHz
: –10˚C to +60˚C; 14˚F to 140˚F
: 5.5 – 11 V DC or specified battery pack
: BP-217 (7.4 V) and BP-216 (3.2 V)
: Negative ground
50/145 MHz
High power
TX
Low power
Rated output
Standby
RX
1
Power saved
*
1
Power save duty is 1:4.
*
: SMA (50 Ω)
: 280 g; 9
7
oz
8
: High
5.0 W typical
Low
0.5 W typical
: Variable reactance modulation
: ±5 kHz
: Less than –60 dB
: 3-conductor 2.5(d) mm (
50.000–52.000, 144.000–146.000, 430.000–440.000
0.495–29.995, 50.000–52.000, 76.000–135.995,
144.000–146.000, 430.000–440.000
440 MHz
2.0 A
2.0 A
0.8 A
1.2 A
220 mA
100 mA
65 mA
×
×
17
(
)
3
7
(
)
1
W
H
32
16
1
); 2 kΩ
8"
1 - 1
(Unit: MHz)
Receiving
0.495–999.990
5
(
) in
D
32
