4. Product installation

4.1. Connect DAEnetIP2 Eight Relay Module to computer for
first time
1 Connect the device with your computer via UTP crossover cable. (note that
the device does not support AUTO MDIX)
2 Supply with 12VDC or 24VDC (depending on selected model) stabilized
filtered power source.
3 Your initial computer IP should be in the device network. So it is recommend
to be 172.16.100.1.
4 Open web browser and type 172.16.100.2 – default username/password are
"admin"/"admin"
5 Now you can access all the parameters via your web browser
4.2. Connect DAEnetIP2 Eight Relay Module to router
1 Do all the steps from 4.1
2 Adjust the network parameters from Setup page:
◦ IP - must be in same network as your router. (For example if router IP is
192.168.1.1, DAEnetIP2 IP may be 192.168.1.2)
◦ Mask
◦ Gateway - usually this is the IP of your router
3 Click submit and wait about 5 seconds
4 Power off the device
5 Now you may disconnect the UTP crossover cable from the DAEnetIP2 and
your computer
6 Connect the DAEnetIP2 module and the network router with UTP straight
cable.
7 Adjust the IP of your computer to be again in the router network
8 Open the web browser and enter the new IP of the module.
