13.

Appendix 5. Firmware upgrade

Bellow are given the steps for firmware upgrade of the DAEnetIP2 Eight Relay
Module (LM35DZ) with DAEnetIP Burner:
1. Download and save the version you need for upgrading the DAEnetIP2 Eight
Relay Module (LM35DZ). The binary (.bin) file must be downloaded from
this link (note the firmware file is different that the firmware file for DAEnetIP2)
2. Navigate the DAEnetIP Burner application to this file by clicking button with
label "...".
3. From the Device list select DAEnetIP2.
4. In the IP address field type the IP address of the DAEnetIP2 controller that
must be upgraded.
5. In the Port field type the port on that DAEnetIP2 can be reached. This is the
SNMP port. By default it is 161.
6. In the Password field type the SNMP password used in this DAEnetIP2
controller. By default it is "private"
7. Check if the settings are correct by clicking button "Check device". After
successful connection under this button it must appears text with the
DAEnetIP2 version. If this not happens it means the connection is not
successful and you must repeat again steps 3-6.
8. Set the TFTP Server. This is usually the IP of the user's computer.
9. Set the maximum retries field. This field shows how many times
the DAEnetIP Burner will try to reconnect with the DAEnetIP2 controller if the
connection is lost for a moment. A value of 5-10 is reasonable.
10. Start update by clicking Burn button. If everything is correct, a new line must
appear in the event log and the progress bar must starts moving on.
DAEnetIP2 Eight Relay Module LM35DZ User Manual
Figure 19. DAEnetIP Burner
21 Aug 2017
-40-
