8.3. Anolog-to-P5 Events
OID Name
x.1.1.121.1.0 aevPin1
x.1.1.121.2.0 aevPin2
x.1.1.121.3.0 aevPin3
x.1.1.121.4.0 aevPin4
x.1.1.121.5.0 aevPin5
x.1.1.121.6.0 aevPin6
x.1.1.121.7.0 aevPin7
x.1.1.121.8.0 aevPin8
DAEnetIP2 Eight Relay Module LM35DZ User Manual
Access Description
read-write Defines reaction on
respective P5 output
pin when voltage is
compared to
thresholds
read-write Defines reaction on
respective P5 output
pin when voltage is
compared to
thresholds
read-write Defines reaction on
respective P5 output
pin when voltage is
compared to
thresholds
read-write Defines reaction on
respective P5 output
pin when voltage is
compared to
thresholds
read-write Defines reaction on
respective P5 output
pin when voltage is
compared to
thresholds
read-write Defines reaction on
respective P5 output
pin when voltage is
compared to
thresholds
read-write Defines reaction on
respective P5 output
pin when voltage is
compared to
thresholds
read-write Defines reaction on
respective P5 output
pin when voltage is
compared to
thresholds
Table 7. Analog-to-P5 Events
Syntax
INTEGER
{ None(0), Low(1),
High(2),
LowHigh(3),
Acc(4) }
INTEGER
{ None(0), Low(1),
High(2),
LowHigh(3),
Acc(4) }
INTEGER
{ None(0), Low(1),
High(2),
LowHigh(3),
Acc(4) }
INTEGER
{ None(0), Low(1),
High(2),
LowHigh(3),
Acc(4) }
INTEGER
{ None(0), Low(1),
High(2),
LowHigh(3),
Acc(4) }
INTEGER
{ None(0), Low(1),
High(2),
LowHigh(3),
Acc(4) }
INTEGER
{ None(0), Low(1),
High(2),
LowHigh(3),
Acc(4) }
INTEGER
{ None(0), Low(1),
High(2),
LowHigh(3),
Acc(4) }
21 Aug 2017
-27-
