8.4. Control port P3 (Digital outputs)
OID
x.1.2.1.1.0 pctrlP3pin1
x.1.2.1.2.0 pctrlP3pin2
x.1.2.1.3.0 pctrlP3pin3
x.1.2.1.4.0 pctrlP3pin4
x.1.2.1.5.0 pctrlP3pin5
x.1.2.1.6.0 pctrlP3pin6
x.1.2.1.7.0 pctrlP3pin7
x.1.2.1.8.0 pctrlP3pin8
x.1.2.1.33.0 pctrlP3byte
8.5. Control port P5 (Digital outputs)
OID Name
x.1.2.2.1.0 pctrlP5pin1
x.1.2.2.2.0 pctrlP5pin2
x.1.2.2.3.0 pctrlP5pin3
x.1.2.2.4.0 pctrlP5pin4
x.1.2.2.5.0 pctrlP5pin5
x.1.2.2.6.0 pctrlP5pin6
x.1.2.2.7.0 pctrlP5pin7
x.1.2.2.8.0 pctrlP5pin8
x.1.2.2.33.0 pctrlP5byte
Name Access
read-
write
read-
write
read-
write
read-
write
read-
write
read-
write
read-
write
read-
write
read-
write
Access
read-write
read-write
read-write
read-write
read-write
read-write
read-write
read-write
read-write
DAEnetIP2 Eight Relay Module LM35DZ User Manual
Description
Port3 pin1 data
Port3 pin2 data
Port3 pin3 data
Port3 pin4 data
Port3 pin5 data
Port3 pin6 data
Port3 pin7 data
Port3 pin8 data
I/O port data as
single byte
Table 10. Control port P5
Description
Port5 pin1 data
Port5 pin2 data
Port5 pin3 data
Port5 pin4 data
Port5 pin5 data
Port5 pin6 data
Port5 pin7 data
Port5 pin8 data
I/O port data as
single byte
21 Aug 2017
Table 9. Control port P3
Syntax
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER(0..255)
Syntax
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER
{ High(1), Low(0) }
INTEGER(0..255)
