Trane RTWD Installation Operation & Maintenance page 13

Table 4 - RTWD High Seasonal Effi ciency - R134a
Indicative performances
Cooling Capacity (1)
Total Power input in cooling (1)
Heating Capacity (2)
Total Power input in heating (2)
Compressor
Compressor Number per Circuit
Type
Model
Evaporator
Quantity
Type
Evaporator model
Evaporator Water Content volume
Two pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s)
Evap. Water Flow rate - Maximum
(3)
Nominal water connection size
(Grooved coupling)
Three pass evaporator
Evap. Water Flow rate - Minimum (3) (l/s)
Evap. Water Flow rate - Maximum
(3)
Nominal water connection size
(Grooved coupling)
Condenser
Quantity
Type
Condenser model
Condenser Water Content volume
Two pass condenser
Cond. Water Flow rate - Minimum
Cond. Water Flow rate - Maximum
Nominal water connection size
(Grooved coupling)
Dimensions (4)
Unit Length
Unit Width
Unit Height
Weights (5)
Shipping Weight
Operating Weight
System data (6)
Nb of refrigerant circuit
Minimum cooling load %
Standard unit
R134a refrigerant charge Circuit1 /
Circuit 2 (6)
Oil charge Circuit1 / Circuit 2
POE Oil type
(1) Indicative performance at Evaporator water temperature: 12°C / 7°C - Condenser water temperature 30°C/35°C - for detailed performances consult
order write up.
(2) Indicative performance at Evaporator water temperature: 10°C / 7°C - Condenser water temperature 40°C/45°C - for detailed performances consult
order write up.
(3) Not applicable for Glycol application - see tables with Minimum Flow with Glycol.
(4) These dimensions are the maximum for a specifi c size, they may vary from one confi guration to another within a same size. For accurate
dimensions of a specifi c confi guration, refer to relevant submittal drawings.
(5) All weights +/-5% and are the maximum for each size and may vary from one confi guration to another for the same size (add 62kg for unit with
acoustic package) and refer to relevant drawing for a specifi c confi guration.
(6) System data are indicative and subject to change without notice. Please refer to unit nameplate data.
RLC-SVX14H-GB
RTWD RTWD
60 70
(kW) 234.8 276.3
(kW) 49.4 58.8
(kW) 250.3 299.2
(kW) 62.0 75.0
# 1/1 1/1
K1/K1 K2/K2
# 1 1
E1AM2 E1AM1
(l) 37.0 40.2
4.5 5.0
(l/s) 16.6 18.4
(in) -
DN100-4' DN100-4'
(mm) (114.3 mm) (114.3 mm) (114.3 mm)
3.0 3.3
(l/s) 11.0 12.2
(in) -
DN80-3' DN80-3'
(mm) (88.9 mm) (88.9 mm) (88.9 mm)
# 1 1
C1AM2 C1AM2
(l) 45.1 45.1
(l/s) 5.4 5.4
(l/s) 19.9 19.9
(in) -
DN125-5' DN125-5'
(mm) (139.7 mm) (139.7 mm) (139.7 mm)
(mm) 3320 3320
(mm) 1130 1130
(mm) 1940 1940
(kg) 2706 2711
(kg) 2788 2796
# 2 2
% 30 30
(kg) 45/45 45/45
(l) 6.8/6.8 6.8/6.8
RTWD RTWD RTWD
80 90 100
316.9 364.7 389.7
67.7 76.9 81.4
340.1 386.8 414.1
85.5 96.7 102.2
1/1 1/1 1/1
Screw
K2/L1 L1/L1 L1/L2
1 1 1
Flooded shell and tube heat exchanger
E1AMJ E2AM2 E2AM2
45.2 57.9 57.9
5.7 7.0 7.0
21.1 25.7 25.7
DN100-4' DN125-5' DN125-5'
(139.7 mm) (139.7 mm)
3.8 4.7 4.7
14.1 17.2 17.2
DN80-3' DN100-4' DN100-4'
(114.3 mm) (114.3 mm)
1 1 1
Shell and Tube Heat Exchanger
C1AMJ C2AM3 C2AM2
52.2 58.1 62.7
6.6 7.3 8.1
24.4 26.9 29.8
DN125-5' DN125-5' DN125-5'
(139.7 mm) (139.7 mm)
3320 3320 3320
1130 1120 1120
1940 1960 1960
2793 2986 3023
2829 3102 3144
2 2 2
30 30 30
45/44 55/55 55/56
6.8/6.8 6.8/6.8 6.8/9.9
OIL048E or OIL023E
General data
RTWD RTWD RTWD
110 120 130
417.4 452.4 487.7
86.6 93.5 100.8
443.9 477.4 512.1
108.5 115.3 122.2
1/1 1/1 1/1
L2/L2 L2/M1 M1/M1
1 1 1
E2AM1 E2AMJ E3AM3
62.3 65.4 72.6
7.7 8.2 8.8
28.2 30.0
DN125-5' DN125-5' DN125-5'
(139.7 mm) (139.7 mm) (139.7 mm)
5.1 5.4 5.9
18.8 20.0 21.6
DN100-4' DN100-4' DN100-4'
(114.3 mm) (114.3 mm) (114.3 mm)
1 1 1
C2AM2 C2AMJ C3AM3
62.7 68.3 81.7
8.1 9.1 10.0
29.8 33.2 36.7
DN125-5' DN125-5' DN150-6'
(139.7 mm) (139.7 mm) (168.3 mm)
3320 3320 3400
1120 1120 1300
1960 1960 1950
3057 3239 3790
3182 3372 3945
2 2 2
30 30 30
55/55 54/54 61/61
9.9/9.9 9.9/9.9 9.9/9.9
13
