6–Configuring RoCE
Preparing the Ethernet Switch
4. Verify the DCB map configuration. Priority group
Dell(conf-dcbmap-roce)# do show qos dcb-map roce
-----------------------
State
PfcMode :ON
--------------------
PG:0 TSA:ETS
Priorities:0 1 2 3 4 6 7
PG:1 TSA:ETS
Priorities:5
5. Apply the DCB map to the port.
Dell(conf)# interface twentyFiveGigE 1/8/1
Dell(conf-if-tf-1/8/1)# dcb-map roce
6. Verify the ETS and PFC configuration on the port.
Dell(conf-if-tf-1/8/1)# do show interfaces twentyFiveGigE 1/8/1 ets
summary
Interface twentyFiveGigE 1/8/1
Max Supported TC is 4
Number of Traffic Classes is 8
Admin mode is on
Admin Parameters :
------------------
Admin is enabled
PG-grp Priority#
------------------------------------------------------------------------
0
1
2
3
Dell(Conf)# do show interfaces twentyFiveGigE 1/5/1 pfc detail
Interface twentyFiveGigE 1/5/1
66 Input TLV pkts, 99 Output TLV pkts, 0 Error pkts, 0 Pause Tx pkts, 0 Pause Rx
pkts
66 Input Appln Priority TLV pkts, 99 Output Appln Priority TLV pkts, 0 Error Appln
Priority TLV Pkts
:Complete
BW:40 PFC:OFF
BW:60 PFC:ON
% Rate(Mbps) Burst(KB) Rate(Mbps) Burst(KB)
0,1,2,3,4,6,7 40
5 60
-
-
Admin mode is on
Admin is enabled, Priority list is 5
Remote is enabled, Priority list is 5
Remote Willing Status is enabled
Local is enabled, Priority list is 5
Oper status is init
PFC DCBX Oper status is Up
State Machine Type is Feature
TLV Tx Status is enabled
PFC Link Delay 65535 pause quntams
Application Priority TLV Parameters :
--------------------------------------
FCOE TLV Tx Status is disabled
ISCSI TLV Tx Status is enabled
Local FCOE PriorityMap is 0x0
Local ISCSI PriorityMap is 0x10
Remote ISCSI PriorityMap is 0x10
BW-% BW-COMMITTED
- - -
- - -
- - -
- - -
53
BW-PEAK TSA
- ETS
- ETS
- -
- -
