MSP430G2231 Automotive Mixed-Signal Microcontroller
1 Features
Qualified for Automotive Applications
1
Low Supply-Voltage Range: 1.8 V to 3.6 V
Ultra-Low-Power Consumption
– Active Mode: 220 µA at 1 MHz, 2.2 V
– Standby Mode: 0.5 µA
– Off Mode (RAM Retention): 0.1 µA
Five Power-Saving Modes
Ultra-Fast Wakeup From Standby Mode in Less
Than 1 µs
16-Bit RISC Architecture, 62.5-ns Instruction
Cycle Time
Basic Clock Module Configurations
– Internal Frequencies up to 16 MHz With One
Calibrated Frequency
– Internal Very Low Power Low-Frequency (LF)
Oscillator
– 32-kHz Crystal
– External Digital Clock Source
16-Bit Timer_A With Two Capture/Compare
Registers
Universal Serial Interface (USI) Supports SPI and
2
I
C
Brownout Detector
10-Bit 200-ksps Analog-to-Digital Converter (ADC)
With Internal Reference, Sample-and-Hold, and
Autoscan
Serial Onboard Programming,
No External Programming Voltage Needed,
Programmable Code Protection by Security Fuse
On-Chip Emulation Logic With Spy-Bi-Wire
Interface
For Family Members Details, See
Characteristics
Available Packages
– 14-Pin Plastic Small-Outline Thin Package
(TSSOP) (PW)
– 16-Pin QFN Package (RSA)
For Complete Module Descriptions, See the
MSP430x2xx Family User's Guide (SLAU144)
1
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
Sample &
Product
Buy
Folder
Device
Tools &
Technical
Software
Documents
SLAS787B – NOVEMBER 2011 – REVISED MARCH 2014
2 Applications
Low-Cost Sensor Systems
3 Description
The Texas Instruments MSP430™ family of ultra-low-
power microcontrollers consists of several devices
featuring different sets of peripherals targeted for
various applications. The architecture, combined with
five low-power modes, is optimized to achieve
extended battery life in portable measurement
applications. The device features a powerful 16-bit
RISC CPU, 16-bit registers, and constant generators
that contribute to maximum code efficiency. The
digitally controlled oscillator (DCO) allows wake-up
from low-power modes to active mode in less than
1 µs.
The MSP430G2231 devices are ultra-low-power
mixed signal microcontrollers with a built-in 16-bit
timer and ten I/O pins. The MSP430G2231 devices
have
a
10-bit
communication
protocols (SPI or I2C). For configuration details, see
Table
1.
Typical applications include low-cost sensor systems
that capture analog signals, convert them to digital
values, and then process the data for display or for
transmission to a host system.
Device Information
ORDER NUMBER
MSP430G2231IRSARQ1
MSP430G2231IPW4RQ1
(1) For the most current part, package, and ordering information,
see the Package Option Addendum at the end of this
document, or see the TI web site at www.ti.com.
Support &
Community
MSP430G2231-Q1
A/D
converter
and
capability
using
synchronous
(1)
PACKAGE
BODY SIZE
(PIN)
RSA (16)
4 mm x 4 mm
PW (14)
5 mm x 4.4 mm
built-in
