- Page 1 HZ108200TX Colorblock 2-Drawer Anywhere Storage Cabinet - For assistance with assembly contact: Southern Enterprises, Inc. Linen Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions www.seidal.com PO#： Page 1...
- Page 2 Colorblock 2-Drawer Anywhere Storage Cabinet - Linen Parts list Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the diagrams below.
- Page 3 Quantity Quantity Quantity of 20 of 16 of 2 Cam Lock Bolt Dia5/16”X1”L Knob Quantity Quantity Quantity of 2 of 16 of 24 Small Bolt Screw Dia1/8”x1”L Screw Dia1/8”x1/2”L Quantity Quantity Quantity of 16 of 1 of 2 Bracket Allen Wrench Screw Dia1/8”x1/2”L Quantity...
- Page 4 Tool List: 3/16" Drill Bit, Drill, Tape Measure, Hammer and Pencil. Colorblock 2-Drawer Anywhere Storage Cabinet - Linen Assembly Instructions Disassemble Metal Slides (16) into Male Metal Slides and Female Metal Slides as shown in Figure 1. Pull the Metal Slides (16) out as far as possible.
- Page 5 When installing the female ball bearings, make sure to start from the front to the back. The front screw must be inserted into the second hole as shown in Figure 2. Attach the Female Ball Bearing Slide (16) on Right Side Panel (D) with Screws (8).
- Page 6 Insert Cam Locks (3) into predrilled holes on assembled unit from Figure 5. Screw Cam Bolts (2) into threaded holes on Bottom Panel (B). Attach assembled unit from Figure 5 to Bottom Panel (B) by inserting Wood Dowels (1) and Cam Bolts (2) into corresponding holes until all panels meet.
- Page 7 Attach Back Panel (H) to the assembled unit from Figure 7 with Screws (9). Tighten Screws with Phillips screwdriver. Figure 8 Insert Cam Locks (2) into corresponding holes on Drawer I /J Bottom Rail (O). Screw Cam Bolt (2) into threaded hole on Drawer Back (M).
- Page 8 Note: Make sure to attach the metal slide with the open end facing towards the back of the drawer. Attach Male Metal Slide (16) to drawer with Screws (8). Tighten screws by Phillips screwdriver. Attach Knob (5) to drawer front with Small Bolt (6).
- Page 9 Move this item close to the wall Bracket (11) and tie in both Bracket (11) with Plastic Strap (12) as shown in diagram. Anti-tipping hardware must be used for this product to avoid tipping and injury. Figure 13 Your Colorblock 2-Drawer Anywhere Storage Cabinet –...
-
Page 10: Parts Replacement Form
Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
