- Page 1 119RU01EN COMPLETE SYTEM FOR RADIO COMMANDS INSTALLATION MANUAL TRA08 English...
-
Page 2: Legend Of Symbols
This symbol tells you what to tell the end-user. 2.1 Intended use 2.1 Intended use The TRA08 kit is for commanding, only by radio, up to four different operators. Any installation and use other than that specified in this manual is forbidden. 4 Description Engineered and built entirely by CAME S.p.A. - Page 3 - fixed 3 second timed monostable”; Protection rating IP54 - fixed 5 minute timed monostable’. Warning! Cut off the main power before acting inside the equipment. 6.1 Dimensions CAME 75 mm 115 mm 87 mm 6.2 Main components 1. Control unit fuse (315 mA - quick) 2.
-
Page 4: Activating The Radio Command
7 TOP-434EE Multi-user channel transmitter Red LED signal light T E CHNI CAL DATA Frequency AM 433.92 MHz two CR2016 - 3 V DC Batteries Lithium Power draw when transmitting 12 mA Effective to 50 ÷ 150 m Code combination 4096 Weight 16 G 8 TOP-433N 8.1 Main components... -
Page 5: Electrical Connections
Radio frequency card Plug in the radio-frequency card onto the electronic board AFTER CUTTING OFF THE MAIN POWER SUPPLY (or disconnecting the emergency batteries). N.B.: The electronic card recognises the radio-frequency card only when it is powered up. Basic Card AF card 10 Electrical connections •... - Page 6 * 10.1 Selecting functions (for each single output) "Maintained action" feature : the relay action lasts as long as the transmitter button is pressed . Fixed 3 second timed monostable”: once the transmitter button is released the relay action lasts 3 seconds.
- Page 7 13 Application example P1 => 1 => OUT1 P2 => 2 => OUT2 CAME Timed walkway lights Apartment block barrier Sectional door to garage zone Timed entrance-stairs lights P3 => 3 => OUT3 P4 => 4 => OUT4...
- Page 8 CAME S.p.A. employs a UNI EN ISO 14001 certified and compliant environmental protection system at its plants, to ensure that environmental safeguarding. We ask you to keep protecting the environment, as CAME deems it to be one of the fundamental points of its market operations strategies, by simply following these brief guidelines when disposing: DISPOSING THE PACKING MATERIALS The packing components (cardboard, plastic, etc.) are solid urban waste and may be disposed of without any particular...
