Electrical power network specification

Voltage (U )
1
Network type
Rated conditional short-circuit
current (IEC 61439-1)
Short-circuit current protection
(UL 508C,
CSA C22.2 No. 14-05)
Frequency
Imbalance
Fundamental power factor
(cos phi )
1

Motor connection data

Motor types
Voltage (U )
2
Frequency
Current
Switching frequency
ACS880-01-xxxx-2 drives: 208 ... 240 V AC 3-phase
+10%...-15%. This is indicated in the type designation
label as typical input voltage level 3
ACS880-01-xxxx-3 drives: 380 ... 415 V AC 3-phase
+10%...-15%. This is indicated in the type designation
label as typical input voltage level 3
ACS880-01-xxxx-5 drives: 380 ... 500 V AC 3-phase
+10%...-15%. This is indicated in the type designation
label as typical input voltage levels 3
V AC.
ACS880-01-xxxx-7 drives: 525 ... 690 V AC 3-phase
+10%...-15%. This is indicated in the type designation
label as typical input voltage levels 3
V AC.
TN (grounded) and IT (ungrounded) systems.
However, 690 V drives must not be installed on corner-
grounded TN systems or corner-grounded IT systems.
65 kA when protected by fuses given in the fuse tables
US and Canada: The drive is suitable for use on a circuit
capable of delivering not more than 100 kA symmetrical
amperes (rms) at 600 V maximum when protected by
fuses given in the fuse table
50/60 Hz, variation ± 5%, maximum rate of change 17%/s
Max. ± 3% of nominal phase to phase input voltage
0.98 (at nominal load)
Asynchronous AC induction motors, permanent magnet
synchronous motors, AC induction servomotors and ABB
synchronous reluctance motors (SynRM motors)
0 to U , 3-phase symmetrical, U
1
point
0...500 Hz
For drives with du/dt filter: 120 Hz
For drives with sine filter: 120 Hz
See section Ratings.
2.7 kHz (typically)
