Pitco 24FF Specifications

Model 24F (FF) & 34F (FF) - High
Capacity Food and Fish Fryers

STANDARD ACCESSORIES

Cabinet - stainless steel exterior
Tank - stainless steel
Food/Fish grid
One drain extension
One drain line clean-out rod
Heat deflector
Submerger (24FF or 34FF only)
Drainboard (24FF or 34FF only)
Tube screen w/handle (24FF or 34FF only)
AVAILABLE OPTIONS & ACCESSORIES
Electric thermostat
Covers
Left or right side work shelf
Top holding shelf with removable tray
Solid state thermostat with melt cycle
Electronic ignition*
Front work shelf
* Only available with solid state thermostat
NOT AVAILABLE on model 24FF
Pitco Frialator, Inc., P.O. Box 501, Concord, NH 03302-0501 1509 Route 3A, Bow NH 03304, USA
Project
Item No.
Quantity

STANDARD SPECIFICATIONS

CONSTRUCTION

CONTROLS

OPERATIONS

APPROVALS
(603) 225-6684 Fax (603) 225-8472 www.pitco.com
L10-012 Rev 8 (11/07)
Welded tank with an extra smooth peened finish
ensures easy cleaning.
Long-lasting, high-temperature alloy stainless steel
heat baffles are mounted in the heat exchanger
tubes to provide maximum heating and combustion
efficiency.
Standing pilot light design provides a ready flame
when heat is required.
Thermostat maintains selected temperature
automatically between 200 F (93 C) and 400 F
(204 C).
Integrated gas control valve acts as a manual and
pilot valve, automatic pilot valve, gas filter, pressure
regulator, and automatic main valve.
Gas control valve prevents gas flow to the main
burner until pilot is established and shuts off all gas
flow automatically if the pilot flame goes out.
Temperature limit switch safely shuts off all gas
flow if the fryer temperature exceeds the upper
limit.
Front 1-1/2" (3.2 cm) full port drain for quick
draining.
Standing pilot and thermostat maintains
temperature automatically at the selected
temperature (200 F (93 C) and 400 F (204 C).
CSA Certified
(AGA, CGA)
NSF Listed
MEA Approved
