Model 24RUFM
Gas Donut Fryer
Shown with optional casters
Pitco Frialator, Inc., P.O. Box 501, Concord, NH 03302-0501 1509 Route 3A, Bow NH 03304, USA
Project
Item No.
Quantity
APPROVALS
(603) 225-6684 Fax (603) 225-8472 www.pitco.com
L10-015 Rev 6 (06/07)
STANDARD SPECIFICATIONS
CONSTRUCTION
Tank constructed of durable stainless steel with an
extra smooth peened finish for easy cleaning.
Long-lasting, high-temperature alloy stainless
steel heat baffles are mounted in the heat
exchanger tubes to provide maximum heating
and combustion efficiency.
Standing pilot light design provides a ready flame
when heat is required.
1/2HP motor used to provide fast filtering
operation. Pumps up to 5 gallons per minute
(18.93 liters).
Filter pan heater
CONTROLS
Thermostat maintains selected temperature
automatically between 200 F (93 C) and 400 F
(204 C).
Integrated gas control valve acts as a manual and
pilot valve, automatic pilot valve, gas filter,
pressure regulator, and automatic main valve.
Gas control valve prevents gas flow to the main
burner until pilot is established and shuts off all
gas flow automatically if the pilot flame goes out.
Temperature limit switch safely shuts off all gas
flow if the fryer temperature exceeds the upper
limit.
OPERATIONS
Standing pilot and thermostat maintains
temperature automatically at the selected
temperature (200 F (93 C) and 400 F (204 C).
Bottom 1-1/4" (3.2 cm) full port drain valve for
quick draining.
Easy to remove under-fryer filter unit for fast
cleaning and paper replacement.
Filter piping integrated into the fryer for no-hassle
CSA Certified
(AGA, CGA)
NSF Listed
MEA Approved
CE Certified
