MAX-MIN Recording

In this mode, the meter records the maximum and minimum values over time.
1. Short press the
display. The maximum and minimum values will be recorded and updated during the
measurement period.
2. Short press the
that occurred during the recording period will be displayed.
3. Short press the
during the recording period.
4. Short press the
period.
5. Long press the

Maintenance

Battery Replacement

1. Power OFF the meter.
2. Remove the flat head screw that secures the battery compartment at the back of the
meter.
3. Open the battery compartment and replace the 3 AAA batteries observing correct polarity.
Re-assemble the meter before use
Safety: Please dispose of batteries responsibly; never dispose of batteries in a fire, batteries may
explode or leak. If the meter is not to be used for 60 days or more, remove the battery and store
separately.
Never dispose of used batteries or rechargeable batteries in household waste.
As consumers, users are legally required to take used batteries to appropriate
collection sites, the retail store where the batteries were purchased, or wherever
batteries are sold.
Disposal: Do not dispose of this instrument in household waste. The user is obligated
to take end-of-life devices to a designated collection point for the disposal of electrical
and electronic equipment.
Cleaning and Storage
Periodically wipe the case with a damp cloth and mild detergent; do not use abrasives or
solvents.
R button to enter the Record mode. The
R button to stop the Max-Min recording. The
R button to display the
H button to clear the memory and start a new max/min measurement
R button to exit record mode.
icon along with the MIN value that occurred
6
record icon will appear on the
icon and the MAX value
AN510-en-GB_V1.0 5/17
