Operation

1. Power the meter by pressing the
intensity readings. If the LCD does not switch on, check the batteries located in the rear
battery compartment.
2. Remove the sensor cover.
3. Aim the light sensor at the light source for the most accurate readings.
4. View the measurement on the meter's LCD

Unit Button

Press the UNIT button to select Lux or Ft-cd. The units will be indicated in the display.

Zero Function

To zero the display, place the light sensor cover over the sensor and press the ZERO button.

Data Hold

Short press the hold (H) button to freeze or unfreeze a reading on the display. The Hold function
is not operational in record mode.

Backlight

The LCD is equipped with backlighting for easier viewing, especially in dimly lit areas. Press the
backlight button to turn the backlight on. The backlight will automatically turn off after 10
seconds.

MAX-MIN Recording

In this mode, the meter records the maximum and minimum values over time.
Note: The Hold and Power buttons are not operational in the Record mode.
1. Short press the
display. The maximum and minimum values will be recorded and updated during the
measurement period.
2. Short press the
that occurred during the recording period will be displayed.
3. Short press the
recording period.
4. Press the H
5. Long press the
R
button to enter the Record mode. The
R
button to stop the Max-Min recording. The
R button to display the
button to clear the memory and start a new max/min measurement period.
R button for to exit the record mode.
power button. The meter will begin displaying light
icon and MIN value that occurred during the
4
record icon will appear on the
icon and the MAX value
