USER MANUAL MODELS: TP-780TXR Extended Range HDMI Line Transmitter + POE TP-780RXR Extended Range HDMI Line Receiver + POE P/N: 2900-300576 Rev 3 www.kramerAV.com... -
Page 4: Table Of Contents
Figure 1: TP-780TXR HDMI Line Transmitter + POE Figure 2: TP-780RXR HDMI Line Receiver + POE Figure 3: Connecting the TP-780TXR/TP-780RXR Transmitter/Receiver Pair Figure 4: Controlling a DVD Player via the TP-780TXR/RXR Figure 5: Controlling an LCD Display via the TP-780TXR/RXR Figure 6: RS-232 Cabling Pinout... -
Page 5: Introduction
Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront video, audio, presentation, and broadcasting professionals on a daily basis. In recent years, we have redesigned and upgraded most of our... -
Page 6: Getting Started
(where appropriate). Achieving the Best Performance To achieve the best performance: For optimum range and performance, use the recommended Kramer cables available at www.kramerav.com/product/TP-780TXR Do not secure the cables in tight bundles or roll the slack into tight coils ... -
Page 7: Recycling Kramer Products
Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at www.kramerav.com/support/recycling/. -
Page 8: Overview
HDBaseT signal that it transmits over twisted pair. The extended HDBaseT signal is decoded by the receiver TP−780RXR, back to HDMI (4K @60Hz 4:2:0), Ethernet, RS−232 and IR output signals. The TP-780TXR and the TP-780RXR can form a transmission and reception system either together or each device separately with another certified HDBaseT device. -
Page 9: About Hdbaset™ Technology
100 meters (330 feet). Beyond this range, a 12V DC power supply must be connected to the PoE receiver. The TP-780TXR is a PoE injector. It cannot receive power from another PoE injector but only from a 48V DC power supply. -
Page 10: Using Twisted Pair Cable
TP-780RXR HDMI IN Connector Connects to the HDMI source PROG/NORMAL Switch Slide to PROG to upgrade to the latest Kramer firmware via RS-232, or slide to NORMAL for normal RS-232 extension operation ETH RJ-45 Connector Connects to a LAN to extend network traffic to the receiver... -
Page 11: Defining The Tp-780Rxr Hdmi Line Receiver + Poe
(HDBaseT PoE) if within range (100m) and green if exceeds range HDBT IN RJ-45 Connector Connects to the HDBT OUT RJ-45 connector on the HDBT transmitter such as TP-780TXR HDMI OUT Connector Connects to the HDMI acceptor... -
Page 12: Connecting The Tp-780Txr And Tp-780Rxr
To connect the TP-780TXR, connect the: 1. HDMI source (for example, a DVD player) to the HDMI IN connector. 2. RS-232 9-pin D-sub connector to a control device (for example, a Kramer RC-43SL control keypad to control the projector). 3. IR 3.5mm mini jack to an IR emitter (for example, to control the DVD). -
Page 13: Figure 3: Connecting The Tp-780Txr/Tp-780Rxr Transmitter/Receiver Pair
Figure 3: Connecting the TP-780TXR/TP-780RXR Transmitter/Receiver Pair TP-780TXR/TP-780RXR - Connecting the TP-780TXR and TP-780RXR... -
Page 14: Remote Control Via An Ir Transmitter
Remote Control via an IR Transmitter Since the IR signal on the TP-780TXR/TP-780RXR transmitter/receiver pair is bidirectional, you can use a remote control transmitter (that is used for controlling a peripheral device, for example, a DVD player) to send commands from either end of the transmitter/receiver system. -
Page 15: Figure 4: Controlling A Dvd Player Via The Tp-780Txr/Rxr
IR sensor cable is connected to the IR connector of the TP-780RXR and an IR emitter cable is connected between the TP-780TXR and the DVD player. The DVD remote control transmitter sends a command while pointing towards the cable-located IR sensor. -
Page 16: Figure 5: Controlling An Lcd Display Via The Tp-780Txr/Rxr
In this example, the IR sensor cable is connected to the IR connector of the TP-780TXR and an IR emitter cable is connected between the TP-780RXR and the LCD display. The LCD display remote control transmitter sends a command while pointing towards the cable-located IR sensor. -
Page 17: Remote Control Via Rs-232
9-wire straight cable to the RS-232 port on your projector. Figure 7 shows bidirectional RS-232 control of the projector that is connected to TP-780RXR, via a RC-43SL connected to the TP-780TXR. The RC-43SL sends commands via RS-232 to control the projector. TP-780TXR/TP-780RXR - Connecting the TP-780TXR and TP-780RXR... -
Page 18: Remote Control Via Ethernet
Remote Control via Ethernet Figure 8 shows bidirectional Ethernet control of the projector that is connected to TP-780RXR, via a RC-43SL connected to the TP-780TXR. The RC-43SL sends commands via Ethernet to control the projector. TP-780TXR/TP-780RXR - Connecting the TP-780TXR and TP-780RXR... -
Page 19: Figure 7: Rs-232 Control Via The Tp-780Txr/Rxr
Figure 8: Ethernet Control via the TP-780TXR/RXR TP-780TXR/TP-780RXR - Connecting the TP-780TXR and TP-780RXR... -
Page 20: Wiring The Extension Line Rj-45 Connectors
Note, that the cable ground shielding must be connected / soldered to the connector shield. Figure 9: Extension Line Pinout EIA /TIA 568B Wire Color Orange / White Orange Green / White Blue Blue / White Green Brown / White Brown TP-780TXR/TP-780RXR - Wiring the Extension Line RJ-45 Connectors... -
Page 21: Technical Specifications
Up to 100m (330ft) at 4K@60Hz (4:2:0), Up to 130m (430ft) at full HD (1080p @60Hz 36bpp), Up to 180m (590ft) at HDBaseT ultra mode and full HD (1080p @60Hz 24bpp), Note: When using Kramer HDBaseT cables MAX. VIDEO RESOLUTION: 4K@60Hz (4:2:0) 24bpp EXTENDED ETHERNET:... -
Page 23: Safety Warning
SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site to find updates to this user manual. We welcome your questions, comments, and feedback.
