Summary of Contents for Kramer TP-9
-
Page 1: User Manual
Kramer Electronics, Ltd. Preliminary USER MANUAL Model: TP-9, Audio/Video Line Transmitter TP-10, Audio/Video Line Receiver... -
Page 2: Table Of Contents
Figure 5: Audio/Video Distribution System up to 300ft (100m) UTP Cable Figure 6: CAT 5 PINOUT Tables Table 1: Features and Functions of the TP-9 Table 2: TP-9 Audio/Video Line Transmitter Underside Features Table 3: Features and Functions of the TP-10 ... -
Page 3: Introduction
Thank you for purchasing the Kramer TOOLS TP-9 Audio/Video Line Transmitter and Kramer TOOLS TP-10 Audio/Video Line Receiver that are ideal for high-quality home cinema installations. The TP-9 and TP-10 uses existing UTP cabling for an efficient, fast and uncluttered environment in: • Studios, airports, offices and hospitals •... -
Page 4: Quick Start
Adjust the EQ. and LEVEL trimmers on the TP-10 if required, by inserting a screwdriver into the small hole and rotating it carefully inserting a screwdriver into the small hole and rotating it carefully Step 4: Operation Operate via the remote controller KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 5: Overview
The IR signal from the remote control is transmitted from the TP-10, via the CAT 5 cable to the TP-9, which is connected to a video source, letting you control the video source via its remote control transmitter from a distance. -
Page 6: About The Power Connect Feature
We recommend that you use Shielded Twisted Pair (STP) cable. There are different levels of STP cable available, and we advise you to use the best quality STP cable that you can afford. Our non-skew-free cable, Kramer BC-STP is intended for analog signals where skewing is not an issue. For cases where there is skewing, our UTP skew-free cable, Kramer BC-XTP, may be used. -
Page 7: Your Audio/Video Line Transmitter And Line Receiver
Your TP-9 Audio/Video Line Transmitter Figure 1 Table 1 define the TP-9 unit: Figure 1: TP-9 Audio/Video Line Transmitter Table 1: Features and Functions of the TP-9 Feature Function CV IN BNC Connector Connects to the composite video source Y/C IN 4-pin Connector... -
Page 8: Figure 2: Tp-9 Audio/Video Line Transmitter Underside
Your Audio/Video Line Transmitter and Line Receiver Figure 2 Table 2 define the switches on the underside of the TP-9: Figure 2: TP-9 Audio/Video Line Transmitter Underside Table 2: TP-9 Audio/Video Line Transmitter Underside Features Feature Function Set to CV to transmit composite video... -
Page 9: Your Tp-10 Audio/Video Line Receiver
Connects to the composite video acceptor Y/C OUT 4-pin Connector Connects to the s-Video acceptor LINE IN RJ-45 Connector Connects to the LINE OUT connector on the TP-9 S/PDIF RCA Connects to the digital audio acceptor Connector ANALOG 3.5mm Mini... -
Page 10: Connecting An Audio/Video Distribution System
(for example, the plasma display’s audio connector) 3. Connect the LINE OUT connector of the TP-9 to the LINE IN connector of the TP-10, via UTP cabling (maximum range of up to 300ft (100m)). 4. On the TP-9 underside, set the VIDEO switch to CV and the AUDIO switch to S/PDIF. -
Page 11: Figure 5: Audio/Video Distribution System Up To 300Ft (100M) Utp Cable
You can now operate the video player via its IR remote controller from a distance. Y / C S / P D I F I N E TP-9 Audio Y / C S / P D I F I N E... -
Page 12: Wiring The Cat 5 Line In/Line Out Rj-45 Connectors
4 and 5 Pair 1 4 and 5 Pair 2 3 and 6 Pair 2 1 and 2 Pair 3 1 and 2 Pair 3 3 and 6 Pair 4 7 and 8 Pair 4 7 and 8 KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 13: Technical Specifications
Technical Specifications Technical Specifications Table 5 defines the technical specifications Table 5: Technical Specifications of the TP-9/TP-10 TP-9 TP-10 INPUTS: 1 RJ-45 CAT-5 shielded connector (LINE IN) 1 composite video 1Vpp/75Ω on a BNC connector 1 s-Video 1Vpp/75Ω [Y], 0.3Vpp/75Ω... - Page 14 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall not be liable for: 1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
- Page 15 For the latest information on our products and a list of Kramer distributors, visit our Web site: www.kramerelectronics.com, where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
