WK-2x User Manual
The minimum system requirements for the WK-2x are:
PC or Mac book compatible with an Ethernet interface
•
Operating system that supports an HTTP Web browser
•
HARDWARE INSTALLATION
The diagrams below depict the configuration using a PoE+ injector or a PoE Switch to power the WK‐2x
Power using PoE+ Injector
Power using PoE+ Switch
8
