WK-2x User Manual
4. Click "OK" to close the dialog, and click "OK" to close the Local Area Connection Properties dialog.
WK‐2X START UP
To configure the WK-2x through a Web Browser, in the address bar of the browser type the IP
address of the WK-2x (default 192.168.1.250) and press Enter.
NOTE: Make sure the Access Point and your computer are configured on the same subnet. To configure
the IP address of your computer, follow the steps in the previous
The WK-2x login dialog appears.
In the User Name box, type pakedge, and in the Password box type pakedgea, and click "Login".
WK-2x IP address:
PC IP address:
PC subnet mask:
192.168.1.250
192.168.1.10
255.255.255.0
section.
11
