Use a single Ethernet cable to connect the camera to the High Power
PoE-enabled switch.
Note: The PoE switch must be able to provide IEEE802.3at High
Power PoE. It is recommended that a Brickcom PS-7242-AT 24
port high power PoE switch be used.
B. If using a non-PoE switch
1. Use a standard Ethernet cable to connect the camera to a High Power
PoE Injector.
2. Use a standard Ethernet cable to connect the High Power PoE Injector
to the non-PoE switch.
3. Use a standard power cable to connect the High Power PoE Injector to
a power outlet.
Note: The PoE injector must be able to provide IEEE802.3at High
Power PoE. It is recommended that a Brickcom POE30U high
power PoE injector be used.
