Basys MX3™ Board Reference Manual
RPB7
RPB2
RPF12
RPD12
RPF8
RPC3
RPE9
RPD9
RPn Port Pin
RPD1
RPG9
RPB14
RPD0
RPD8
RPB6
RPD5
RPF3
RPF6
RPF13
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
RPB7R
RPB2R
RPF12R
RPD12R
RPF8R
RPC3R
RPE9R
RPD9R
RPnR SFR RPnR Value to Peripheral Selection
0000 = No Connect
RPD1R
0001 = U2RTS
0010 = Reserved
0011 = U1RTS
RPG9R
0100 = U5TX
0101 = Reserved
0110 = SS2
RPB14R
0111 = Reserved
1000 = SDO1
1001 = Reserved
RPD0R
1010 = Reserved
1011 = OC2
1100 = OC1
RPD8R
1101 = Reserved
1110 = Reserved
1111 = Reserved"
RPB6R
RPD5R
RPF3R
RPF6R
RPF13R
