Appendix 2: Remappable Output Pins

RPn Port Pin
RPD2
RPG8
RPF4
RPD10
RPF1
RPB9
RPB10
RPC14
RPB5
RPC1
RPD14
RPG1
RPA14
RPn Port Pin
RPD3
RPG7
RPF5
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
RPnR SFR RPnR Value to Peripheral Selection
RPD2R
RPG8R
0000 = No Connect
0001 = U3TX
RPF4R
0010 = U4RTS
0011 = Reserved
0100 = Reserved
RPD10R
0101 = Reserved
0110 = SDO2
0111 = Reserved
RPF1R
1000 = Reserved
1001 = Reserved
1010 = Reserved
RPB9R
1011 = OC3
1100 = Reserved
1101 = C2OUT
RPB10R
1110 = Reserved
1111 = Reserved
RPC14R
RPB5R
RPC1R
RPD14R
RPG1R
RPA14R
RPnR SFR RPnR Value to Peripheral Selection
0000 = No Connect
RPD3R
0001 = U2TX
0010 = Reserved
0011 = U1TX
RPG7R
0100 = U5RTS
0101 = Reserved
0110 = SDO2
RPF5R
0111 = Reserved
