Appendix 1: Remappable Input Pins

Peripheral Pin [pin name]R SFR
INT3 INT3R
T2CK T2CKR
IC3 IC3R
U1RX U1RXR
U2RX U2RXR
U5CTS U5CTSR
REFCLKI REFCLKIR
Peripheral Pin [pin name]R SFR
INT4 INT4R
T5CK T5CKR
IC4 IC4R
U3RX U3RXR
U4CTS U4CTSR
SDI1 SDI1R
SDI2 SDI2R
Peripheral Pin [pin name]R SFR
INT2 INT2R
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
[pin name]R bits [pin name]R Value to RPn Pin Selection
INT3R<3:0>
0000 = RPD2
0001 = RPG8
T2CKR<3:0>
0010 = RPF4
0011 = RPD10
0100 = RPF1
IC3R<3:0>
0101 = RPB9
0110 = RPB10
0111 = RPC14
U1RXR<3:0>
1000 = RPB5
1001 = Reserved
1010 = RPC1
U2RXR<3:0>
1011 = RPD14
1100 = RPG1
1101 = RPA14
U5CTSR<3:0>
1110 = Reserved
1111 = RPF2
REFCLKIR<3:0>
[pin name]R bits [pin name]R Value to RPn Pin Selection
INT4R<3:0>
0000 = RPD3
0001 = RPG7
T5CKR<3:0>
0010 = RPF5
0011 = RPD11
0100 = RPF0
IC4R<3:0>
0101 = RPB1
0110 = RPE5
0111 = RPC13
U3RXR<3:0>
1000 = RPB3
1001 = Reserved
1010 = RPC4
U4CTSR<3:0>
1011 = RPD15
1100 = RPG0
1101 = RPA15
SDI1R<3:0>
1110 = RPF2
1111 = RPF7
SDI2R<3:0>
[pin name]R bits [pin name]R Value to RPn Pin Selection
0000 = RPD9
INT2R<3:0>
0001 = RPG6
