Do not leave the Drum Cartridge Drawer open for more than one minute. Exposing the
drum cartridges to direct sunlight or strong light from indoor fluorescent lighting for
more than one minute may cause image quality defects.
Replace drum cartridges while the press is powered ON.
1. Ensure that the press is stopped and is not currently printing jobs.
2. Open the press Front Door.
3. Rotate and turn the R1-R4 Drum Drawer Handle to the unlock position.
4. Open the bag containing the new drum cartridge. Place the new drum cartridge near
Do not touch or scratch the surface of the drum when you take it out from the bag.
