Wall Mounting

Before you begin, you need 2 wallboard screws (included) to mount the
access point. We recommend using screws with a minimum of 4mm width
at the head and a shaft diameter of at least 1.5mm.
Cisco is not responsible for damages incurred by insecure wall-
W
ARNING
mounting.
To mount the access point to the wall:
Determine where you want to mount the access point. Verify that
S 1
TEP
the surface is smooth, flat, dry, and sturdy.
Drill two pilot holes into the surface 5.75 inches (146 mm) apart,
S 2
TEP
and with a minimum of 4.0 inches (101 mm) of clearance.
Insert a screw into each hole, leaving a gap between the surface
S 3
TEP
and the base of the screw head of at least 0. 1 inches (3 mm).
Place the access point wall-mount slots over the screws and slide
S 4
TEP
the access point down until the screws fit snugly into the wall-
mount slots.
