Shock Setup - Intense Cycles Recluse User Manual

shock setup

rock shox monarch rC3 / R 200 x 57mm
set up and tune
proper set up and tuning can
vary from shock to shock. Please
consult the rockshox manual
included with your bike for complete
information about set up, tuning
and general maintenance or visit
www.sram.com/rockshox/products
Travel
Shock Stoke
Shock Sag
Fork Sag
SHOCK: Recluse 275 Expert Rock Shox Monarch RC3 200x57 mm DB2 MM S 320
SHOCK: Recluse 275 Foundation Rock Shox Monarch R 200x57 mm DB2 MM S 320
RIDER WEIGHT (LBS/KGS) SPRING (PSI)
100 LBS / 45 KGS
80
110 LBS / 50 KGS 88
120 LBS / 54 KGS
97
130 LBS / 59 KGS 105
140 LBS / 63.5 KGS
114
150 LBS / 68 KGS 122
160 LBS / 73 KGS
131
170 LBS / 77 KGS 139
180 LBS / 82 KGS 148
190 LBS / 86 KGS 156
200 LBS / 91 KGS 164
210 LBS / 95 KGS 173
220 LBS / 100 KGS 181
230 LBS / 104 KGS
190
240 LBS / 109 KGS 198
250 LBS / 113 KGS
207
260 LBS / 118 KGS 215
270 LBS / 122 KGS
224
280 LBS / 127 KGS 232
290 LBS / 131.5 KGS
241
300 LBS / 136 KGS 249
I N T E N S E
140 mm
57 mm
20% when sitting on the bike
25-30% when sitting on the bike
REBOUND (clicks out)
2 to 3
3 to 4
5 to 6
C Y C L E S / / 1 5
