Intense Cycles Recluse User Manual page 7

ITEM PART
ITEM
NO. NUMBER
Derailleur Mount
1 130209
Cover
2 Box Link 130764
Bearing Cap
3 130765
24mm OD
4 Bearing Cap 130778
5
Axle Upper 130780
6
Bolt Shoulder 130785
7 Spacer 130789 Top Link Bearing Spacer (Upper)
8
Hanger 130790
9 Bolt Main Pivot 130791
10 Hanger Bolt 130792
11 Rear Axle 130799
12
Cone Adjuster 130807 Cone Adjuster Blk, 8.3 mm Height
13 Top Link 130808
14
Bumper 140006
15 O-Ring 140013
16
Plug 140038
Cable Guide
17 140039
Grommet
18 Cable Guide Plug 140040
Cable Guide
19 140042
Grommet
20 Clip 310001
21 Seat Collar 346941
DESCRIPTION QTY. TORQUE SPEC.
For Single Ring Setup 1 N/A
Forged Lower Link 1 N/A
Top Link Bearing Spacer
2 N/A
(Lower)
Box Link Bearing Cap 4 N/A
Top Link Pivot Axle 20 Nm /
1
(Upper) 175 in-lbs
20 Nm /
Top Link Pivot Bolt 1
175 in-lbs
2 N/A
Derailleur Hanger Forged 1 N/A
7 Nm /
Box Link Expander Bolt 3
60 in-lbs
11 Nm /
Derailleur Hanger Bolt 1
100 in-lbs
11 Nm /
Axle 148 x 12 Boost 1
100 in-lbs
3 N/A
Forged Top Link 1 N/A
Box Link Bumper 1 N/A
Seat Clamp o-ring 1 N/A
Box Link Pivot Plug 3 N/A
Cable Guide Grommet
2 N/A
(Head Tube)
Cable Guide Plug (Thru) 8 N/A
Cable Guide Grommet
1 N/A
(Rear Triangle)
Cable Guide Clip 2 N/A
Bolt-on 36.1 Blk 1 N/A
ITEM PART
ITEM
NO. NUMBER
22
Zerk Fitting 401011
Water Bottle Bolt, Button Head,
23 BHCS M5 X 12 410010
Cone Adjuster Bolt, Socket Head,
24 SHCS M6 x 22 410032
Cone Adjuster Bolt, Socket Head,
24ST SHCS M6 x 22 410009
25 FHCS M6 x 12 410037
Front Shock Bolt, Socket Head,
26
SHCS M6 x 40 410050
Front Shock Bolt, Socket Head,
26ST
SHCS M6 x 40 410053
Rear Shock Bolt, Socket Head,
27 SHCS M6 x 45 410051
Rear Shock Bolt, Socket Head,
27ST SHCS M6 x 45 410054
28 Bearing 7902 430007
MAX Angular Contact Bearing
29 Bearing 6802 430008
30
Guard Flack SS 500254
31 Protector Chainstay 500255
32 Guard Flack DT 500256
33 Guard Flack CS 500259
34 Decal 500300
35 Head Badge 500335
36 Front Triangle
37
Rear Triangle
38 Rear Shock Shock
I N T E N S E
DESCRIPTION QTY. TORQUE SPEC.
5 Nm /
M6 x 1.0 2
40 in-lbs
6 Nm /
2
M5 X 12 54 in-lbs
14 Nm /
3
M6 x 22 Titanium 125 in-lbs
14 Nm /
3
M6 x 22 Stainless Steel 125 in-lbs
Front Derailleur Mount Bolt, 7 Nm /
1
Flat Head, M6 x 12 Blk 60 in-lbs
7 Nm /
1
M6 x 40 Titanium 60 in-lbs
7 Nm /
1
M6 x 40 Stainless Steel 60 in-lbs
7 Nm /
1
M6 x 45 Titanium 60 in-lbs
7 Nm /
1
M6 x 45 Stainless Steel 60 in-lbs
15 x 28 x 7 2RS
4 N/A
15 x 24 x 5 2RS
4 N/A
MAX Radial Bearing
Flack Guard Seatstay 1 N/A
Protector Chainstay 1 N/A
Flack Guard Down Tube 1 N/A
Flack Guard Chainstay 1 N/A
Decal California Bear 1 N/A
Head Badge Flame Logo 1 N/A
Carbon - 4 Sizes 1 N/A
Carbon - 1 Size 1 N/A
7.875in x 2.25in
1 N/A
(200mm x 57mm)
C Y C L E S / / 7
