Intense Cycles Recluse User Manual page 16

shock setup
FOX FLOAT X2 200 x 57mm
set up and tune
proper set up and tuning can vary
from shock to shock. Please
consult the Fox manual included
with your bike for complete
information about set up, tuning
and general maintenance or visit
www.foxracingshox.com
1 6 / / r e c l u s e u s e r m a n u a l
Travel
Shock Stoke
Shock Sag
Fork Sag
SHOCK: Recluse 275 Factory
FOX Shox, FLOAT X2, F-S, K, 2POS Lever, 200x57 mm
SHOCK: Recluse 275 Pro FOX Shox, FLOAT X2, P-SE, A, 2POS Lever, 200x57 mm
RIDER WEIGHT(LBS/KGS)
100 LBS / 45 KGS
110 LBS / 50 KGS
120 LBS / 54 KGS
130 LBS / 59 KGS
140 LBS / 63.5 KGS
150 LBS / 68 KGS
160 LBS / 73 KGS
170 LBS / 77 KGS
180 LBS / 82 KGS
190 LBS / 86 KGS
200 LBS / 91 KGS
210 LBS / 95 KGS
220 LBS / 100 KGS
230 LBS / 104 KGS
240 LBS / 109 KGS
250 LBS / 113 KGS
260 LBS / 118 KGS
270 LBS / 122 KGS
280 LBS / 127 KGS
290 LBS / 131.5 KGS
300 LBS / 136 KGS
140 mm
57 mm
20% when sitting on the bike
25-30% when sitting on the bike
SPRING (PSI)
100
111
121
132
142
152
163
173
184
194
204
215
225
235
246
256
267
277
287
298
308
