Nevco MPCW-7 Control Operator's Manual page 3

A. MPCW Control
B. Power Supply
C. Overlay
D. Hand Held Switch
E. Keypads
F. 16 Character Display
G. Power On / Off Switch
Jack for Hand Held
H.
Switch
Figure 1 – MPCW Control (front view)
Can operate scoreboards for a wide range of sports and features.
9 V DC (included with the control)
Fits on top of control to label the keys (included with system)
One TCS-7 time control switch is included with each control.
Additional switches are included with the accessories they operate.
Left and Right (20 keys each)
Bright LED for better visibility
Controls power to the MPCW (does NOT control scoreboard power)
One on each side of control (use either jack for any Hand Held switch)
